Fine grind air swept mill Approx 1000 CFM. Unit fine grinds and classifies. Features of this unit are Dust free operation, ease of mainteneance, and an exceptional ratio of product yeils to energy consumption. Simple adjustments to the machine allow for a narrow distibution range of output particles on wet, dry, fiberous, or heat sensitive materials. Capable of grinding down to the 5 micro range with maximum plates and speed. Mill speed of 1800 rpm, includes self contained lube system and volumetric feeder. Mian mill rotates counter clockwise 3/60/230/460V through a lubricated shaft. All seals purged with air/nitrogen. On board oil system features 12 gallon lube oil storage tank with self contained pump & regulator including sight glass. On board Volumetric feeder, 304SS, features a 4" screw with a 12" x 16" hopper, is chain driven by a 1 hp electric motor through a gear box.
Type: Pulverizer
Subtype: Granulator/Disintegrator
Manufacturer: Alpine (Hosokawa)
Model: 450MM
Condition: Used
Material: Stainless Steel 304
Outlet Discharge Diameter: 559 mm (22 in)
Inlet Diameter: 635 mm (25 in)
Top feed, gravity discharge. Has (16) fixed blades, sharp on one side, on 24" (620mm) long rotor. Rotor belt driven by 5 HP (3.7 KW), 3/50/380 volt,X-proof motor Has outboard bearing and removable rotor 25" x 10" feed, 22" x 16" discharge Housing on hinge.
Motor Power (Design): 3.7 kW (5 HP). Orientation: Horizontal.
Type: Pulverizer
Subtype: Granulator/Disintegrator
Manufacturer: Alpine (Hosokawa)
Model: 450mm dia x 620 L
Condition: Used
Material: Stainless Steel 304
Outlet Discharge Diameter: 559 mm (22 in)
Inlet Diameter: 635 mm (25 in)
Top feed, gravity discharge. Has (16) fixed blades, sharp on one side, on 24" (620mm) long rotor. X-proof motor. Has outboard bearing and removable rotor. 25" x 10" feed, 22" x 16" discharge Housing on hinge.
Motor Power (Design): 3.7 kW (5 HP). Orientation: Horizontal.
Type: Pulverizer
Subtype: Granulator/Disintegrator
Manufacturer: Alpine (Hosokawa)
Model: 450MM
Condition: Used
Material: Stainless Steel 304
Outlet Discharge Diameter: 559 mm (22 in)
Inlet Diameter: 635 mm (25 in)
Top feed, gravity discharge Has (16) fixed blades, sharp on one side, on 24" (620mm) long rotor. Has outboard bearing and removable rotor. 25" x 10" feed, 22" x 16" discharge Housing on hinge.
Motor Power (Design): 3.7 kW (5 HP). Orientation: Horizontal.
Type: Pulverizer
Subtype: Granulator/Disintegrator
Manufacturer: Fitzpatrick
Model: DAS06
Condition: Used
Material: Stainless Steel 304
Motor Power (Design): 7.5 kW (10 HP)
w/screw feed driven by gearhead motor 10 HP belt drive for mill.
