Showing 25 of 55 matching Granulator/Disintegrator.
UPZ 315 highly polished 316L stainless steel fine impact mill with pin disc grinding system consisting of:
(1) UPZ 315 highly polished 316L stainless steel pin disc mill, manufactured by Hosokawa, serial #P1 125 630/1, asset #12302, 4500 rpm,(max 9200 rpm), permissible overpressure 0.09 bar @ 50 degrees C, inside 34 liter, pin size 7mm diameter x 35mm long, (236) pins on door side, (231) pins on drive side, plate beater diameter 298mm, (10) plate beaters, mill driven by approx 18kw motor
(1) 13.5 square meter 316L stainless steel vertical heat exchanger (gas cooler), manufactured by Transitherm GmbH, type WTGDP 273/2400 1-PASS, fabrik #10830, design pressure tube side -1/10 bar @ -29/100 degrees C (82 liter), shell side -1/10 bar @ -29/100 degrees C (76 liter), TUV, (132) 14mm diameter x 1 x 2.4m long 316L stainless steel tubes, single pass tube side, 273mm diameter 316L stainless steel shell
(2) 316L stainless steel heads with 90 degree bend, openings tube side each head with a 150mm, shell: 2-75mm, mounted on lugs
(1) stainless steel screw feeder
(1) 22 square meter polished 316L stainless steel reverse jet dust filter, manufactured by Hosokawa Alpine, type AR 34 M, serial #P1 140 710/1, pressure -0.1/+0.49 bar @ -29/80 degrees C, stainless steel polished to Ra max 0.5um, 1.3m diameter x 2m straight side x 1250mm bottom cone section, clamp bonnet head, (34) 130mm diameter x 1820mm long internal filter cages, 6-sets of valves
(1) highly polished 316L stainless steel cantilever rotary sifter, ATEX zone 22, manufactured by Kemutec Powder Technologies Ltd, type K650C sifter, serial #K650C A10942/1, asset #12230, working pressure -0.1/0.49 barg, design temperature 40 degrees C max, driven by 2.2kw, 3/50/415 volt 1500 rpm EExde IIB T4 zone 1 & 22, motor, mounted on a stainless steel frame with wheels
(1) 25m3/hr @ 7.06m head 316L stainless steel centrifugal pump, manufactured by HMD Sealless Pumps, serial #824545, type GSI 80-50-200 D-4A, NPSHa 19.68m, driven by 1.1kw, 3/50/415 volt 1450 rpm EExd IIB T4 motor, mounted on a baseplate
(1) 15 m3/minute 316L stainless steel Radial blower/fan, manufactured by Reitz, type single stage KXE080-001430-00, serial #175747, total pressure increase 746 daPa, impellor speed 3000 rpm, inlet size 140mm, discharge 100mm, driven by 7.5kw, 3/50/415 volt 3000 rpm EExdeIIBT4 motor
(1) 160mm diameter polished 316L stainless steel motorised rotary valve, manufactured by Engelsmann, type ZSA 200, driven by 0.55kw, 3/50/415 volt 10 rpm EExdIICT4 motor
(1x) stainless steel Lowbotech discharge unit with metal detector
(1x) 316L stainless steel Matcon Hopper discharge unit,
1000 kg/h 120x160 mm drum screen, scraper drum 120x160 mm
Alexanderwerk Pharma pressure internal -1/3 bar @ 145 deg C (91ltr), jacket -1/3.3 bar @ 145 deg C (13ltr) underdriven by a DIETZ 400-690 Volt
stainless steel (polished) Frewitt Delumper with crushing and grinding system, type Delumpwitt, upto 9000kg/hr flow rate, system includes: (1) stainless steel Frewitt Conwitt 250 conical sieve mill, serial #12014519069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) stainless steel infeed hopper, (1) stainless steel Frewitt crushing unit, serial #12014532028, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) Frewitt Conwitt 250 vibrating unit, serial #1201459069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) servolift elevating/lifting machine, serial #12885, all mounted on a stainless steel frame
100 kg typical batch weight (Polished to a 0.1 Ra Min finish) Standard capacity range is 120-240 liters. This granulator features a through the wall design where the utilities are located outside the clean room. It has a jacket for the base and bowl with temperature sensor. The main impeller is capable of being raised and lowered. The side chopping system has a variable speed control. Discharge is into a through the wall mill model U-20. Features sanitary design and Clean in place. This multipurpose machine can process dry powders, aqueous and solvent granulations, effervescent products, and melt palletization applications. This machinery is electronically controlled. Can be used with Fluid bed dryer IPP stock # 233968.
Pressure shock resistant design
Rated for 1500 kg./Hr,
pressure 11 bar at 70 degrees C,
side bottom inlet 390mm diameter and 125mm diameter,
top discharge 340mm,
36 pin disk underdriven by 45kW, 3/60/460 volt, 1775 rpm IP65 motor,
24 blade classifier under driven by 11kW, 3/60/460 volt, 1760 rpm motor,
Classifier is rated max. 3100 rpm.
speed 720 to 1775 rpm.
400mm air intake nozzle,
hinged top cover with manually operated opening mechanism
Coffee grinder
rated: 11 DCuM, 0.05 bar, 60°C., 10 bar overpressure stud disc diameter: 315 mm, plate beater: 298 mm, swing beater: 298mm, air inlet: DN 100 mm
oscillating granulator. milling chamber 370 mm wide x 550 mm long 3~ 380V/220V 2,7A/4,7A 1,1 kW; 50Hz completely enclosed in stand
construction with 360 degree SS screen.
Designed for industrial duty, for mixing and depluming of slurries, pastes, liquids, and resins and shredding
Unit has vertical shaft with horizontal rotating knives, 360 degrees screen discharge.
1000 kg/h 120x160 mm drum screen, scraper drum 120x160
bare mill only. (no drive).
Air flow and power requirement are 6000 acfm,
Fan power 40 Hp.,
Mill power minimum 50 HP, maximum 100 HP.
The Imp mill is designed for low cost, dependable, grinding for fine to medium grinds.
14 hp 380-660 volt, IP54, vibrating pan feeder magnetic separator driven by 0.25 kw, 3/50/380-220 volt 1370 rpm, ex proof motor. Gear box of the Mill is water cooled
Machine # 04531460 1 x perforated die cylinder 70MM diameter with 1mm holes and 1 x solid pressure cylinder 60mm diameter working length 80mm Approximate throughput range 30-50 kg/hr. Driven by us Motor series 2000. Ratio : 4, output torque 520 lbs. Hazardous location class 1, group D, class II, groups F&G.
oscillating screen granulator volt 3 x 380, 7.65 amp, vari-speed motor
Fine grind air swept mill Approx 1000 CFM. Unit fine grinds and classifies. Features of this unit are Dust free operation, ease of mainteneance, and an exceptional ratio of product yeils to energy consumption. Simple adjustments to the machine allow for a narrow distibution range of output particles on wet, dry, fiberous, or heat sensitive materials. Capable of grinding down to the 5 micro range with maximum plates and speed. Mill speed of 1800 rpm, includes self contained lube system and volumetric feeder. Mian mill rotates counter clockwise 3/60/230/460V through a lubricated shaft. All seals purged with air/nitrogen. On board oil system features 12 gallon lube oil storage tank with self contained pump & regulator including sight glass. On board Volumetric feeder, 304SS, features a 4" screw with a 12" x 16" hopper, is chain driven by a 1 hp electric motor through a gear box.
fine impact stud mill Unit has (1) rotary disc 13.6" (340mm) dia w/(136) 1/4" studs; (1) stationary disc w/(200) 1/4" studs. Vibrating pan feeder with 1/2 HP (0.39 KW), 3/50/500 volt, 2250 rpm motor. W/(1) spare pin-disc set. (1) set of beater discs. Unit is similar to Alpine UPZ mill.
Biplex cross flow separator mill. Type Biplex Gravity feed with 6" diameter rotolock UL label. Feeder belt was driven by 1/4 HP, 3/50/380 volt motor (motor required) , UL label. Max mill rpm 3350, min mill rpm 2800.
Contraplex CS impact stud mill. 10mm dia x 46mm long high CS pins 3/50/380/660 volt UL label. Door rotor belt driven by 14 HP (11 KW), 3/50/380/660 volt, 1440 rpm motor, UL label. Housing rotor has (3) rows, (143) pins. Pin disc max 8400 rpm. Door pin disc (3) rows, (134) pins, max 4500 rpm. Pins on mill and door are 1 1/8".
15HP CS Alpine pin mill, 2500 rpm rotor Hinged front door. Mill is designed for belt drive. No motor w/unit.
oscillating granulator, W/feed hopper
48 kw contraplex wide chamber impact pin mill with 2-driven counter rotating pin discs throughput 1.2 ton/hour housing disc belt driven by 48kw, 3/50/660 volt, 1480/2800 rpm Ex II T3 motor, front door disc belt driven by 36/49kw, 3/50/660 volt, 1150/1550 rpm Ex II T3 motor, hinged front door,
contraplex wide chamber impact pin mill with 2-driven counter rotating pin discs throughput 800 KG/hour, housing disc belt driven by 23kw, 3/50/660 volt, 1500 rpm Ex II T3 motor, front door disc belt driven by 23kw, 3/50/660 volt, 1500 rpm Ex II T3 motor, hinged front door
"Extructor"
Used pulverizer equipment from IPP encompasses a wide range of machinery essential for material size reduction and processing. Whether you require hammer mills, jet mills, or fluid energy mills, IPP offers equipment that meets your specific needs. With over 47 years of industry experience, IPP supplies used, surplus, and secondhand pulverizer equipment from 20 global plant sites and maintains a ready-to-ship inventory of 15,000+ process systems.
IPP stocks equipment from leading manufacturers such as Mikro Pulverizer, Fitzpatrick, and Hosokawa, ensuring quality and reliability.
To ensure durability and compliance, pulverizer equipment is typically constructed from:
