Showing 25 of 101 matching Pulverizers.
UPZ 315 highly polished 316L stainless steel fine impact mill with pin disc grinding system consisting of:
(1) UPZ 315 highly polished 316L stainless steel pin disc mill, manufactured by Hosokawa, serial #P1 125 630/1, asset #12302, 4500 rpm,(max 9200 rpm), permissible overpressure 0.09 bar @ 50 degrees C, inside 34 liter, pin size 7mm diameter x 35mm long, (236) pins on door side, (231) pins on drive side, plate beater diameter 298mm, (10) plate beaters, mill driven by approx 18kw motor
(1) 13.5 square meter 316L stainless steel vertical heat exchanger (gas cooler), manufactured by Transitherm GmbH, type WTGDP 273/2400 1-PASS, fabrik #10830, design pressure tube side -1/10 bar @ -29/100 degrees C (82 liter), shell side -1/10 bar @ -29/100 degrees C (76 liter), TUV, (132) 14mm diameter x 1 x 2.4m long 316L stainless steel tubes, single pass tube side, 273mm diameter 316L stainless steel shell
(2) 316L stainless steel heads with 90 degree bend, openings tube side each head with a 150mm, shell: 2-75mm, mounted on lugs
(1) stainless steel screw feeder
(1) 22 square meter polished 316L stainless steel reverse jet dust filter, manufactured by Hosokawa Alpine, type AR 34 M, serial #P1 140 710/1, pressure -0.1/+0.49 bar @ -29/80 degrees C, stainless steel polished to Ra max 0.5um, 1.3m diameter x 2m straight side x 1250mm bottom cone section, clamp bonnet head, (34) 130mm diameter x 1820mm long internal filter cages, 6-sets of valves
(1) highly polished 316L stainless steel cantilever rotary sifter, ATEX zone 22, manufactured by Kemutec Powder Technologies Ltd, type K650C sifter, serial #K650C A10942/1, asset #12230, working pressure -0.1/0.49 barg, design temperature 40 degrees C max, driven by 2.2kw, 3/50/415 volt 1500 rpm EExde IIB T4 zone 1 & 22, motor, mounted on a stainless steel frame with wheels
(1) 25m3/hr @ 7.06m head 316L stainless steel centrifugal pump, manufactured by HMD Sealless Pumps, serial #824545, type GSI 80-50-200 D-4A, NPSHa 19.68m, driven by 1.1kw, 3/50/415 volt 1450 rpm EExd IIB T4 motor, mounted on a baseplate
(1) 15 m3/minute 316L stainless steel Radial blower/fan, manufactured by Reitz, type single stage KXE080-001430-00, serial #175747, total pressure increase 746 daPa, impellor speed 3000 rpm, inlet size 140mm, discharge 100mm, driven by 7.5kw, 3/50/415 volt 3000 rpm EExdeIIBT4 motor
(1) 160mm diameter polished 316L stainless steel motorised rotary valve, manufactured by Engelsmann, type ZSA 200, driven by 0.55kw, 3/50/415 volt 10 rpm EExdIICT4 motor
(1x) stainless steel Lowbotech discharge unit with metal detector
(1x) 316L stainless steel Matcon Hopper discharge unit,
Mikro Atomizer Rated for 6,000 rpm. Capable of handling capacities from 100 to 1000 lbs/hr, dependent on the material, this machine handles 3 functions in one machine. Pulverizes, air classifies and conveys the material.
1000 kg/h 120x160 mm drum screen, scraper drum 120x160 mm
Alexanderwerk Pharma pressure internal -1/3 bar @ 145 deg C (91ltr), jacket -1/3.3 bar @ 145 deg C (13ltr) underdriven by a DIETZ 400-690 Volt
Single Rotor Crusher fixed hammers. Crusher walls are 1/4" thick, shaft is 1 15/16" diameter. Unit has a SS feed chute, screen discharge with 1/2" holes230/460 volt motor.
10 HP Fixed knives blunt one side, w/reversible rotor. Unit driven by approx 10 HP, US varidrive. Screw feed driven by 1/4 HP, 3/60/230/460 volt US varidrive 3/60/230/460 volt US varidrive.
w/(3) feed screws. Discharge hopper w/out valve Stirrup type hammers. Rotor belt driven by 30 HP, 3/60/230/460 volt, 1770 rpm TEFC motor. Feeder belt driven by 1/2 HP, 3/60/220/440 volt, 1140 rpm TEFC motor.
stainless steel (polished) Frewitt Delumper with crushing and grinding system, type Delumpwitt, upto 9000kg/hr flow rate, system includes: (1) stainless steel Frewitt Conwitt 250 conical sieve mill, serial #12014519069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) stainless steel infeed hopper, (1) stainless steel Frewitt crushing unit, serial #12014532028, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) Frewitt Conwitt 250 vibrating unit, serial #1201459069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) servolift elevating/lifting machine, serial #12885, all mounted on a stainless steel frame
100 kg typical batch weight (Polished to a 0.1 Ra Min finish) Standard capacity range is 120-240 liters. This granulator features a through the wall design where the utilities are located outside the clean room. It has a jacket for the base and bowl with temperature sensor. The main impeller is capable of being raised and lowered. The side chopping system has a variable speed control. Discharge is into a through the wall mill model U-20. Features sanitary design and Clean in place. This multipurpose machine can process dry powders, aqueous and solvent granulations, effervescent products, and melt palletization applications. This machinery is electronically controlled. Can be used with Fluid bed dryer IPP stock # 233968.
fluidised opposed jet milling (grinding air pressure 6 barg, nozzle 0 16mm), 1250 dm3 grinding bin volume, 80 mbar permissible operating pressure in grinding bin, max operating pressure in grinding bin, 5- nozzles, nozzle diameters 14mm, 16mm, 18mm, classifier has 3-wheels, each wheel with 60 vanes wide pitch, narrow pitch 120 vanes, max wheel speed 4000 rpm each whees driven by 5.12 - 16 kw,3/50/415 volt, 940/2940 rpm motor, (1) 1100 liter carbon steel feed hopper weld dished top, weld coned bottom, bottom outlet with 150mm diameter carbon steel screw conveyor, 15.1 rpm speed,
fluidised opposed jet milling (grinding air pressure 6 barg, nozzle 0 16mm) 1250 dm3 grinding bin volume, 80 mbar permissible operating pressure in grinding bin, max operating pressure in grinding bin, 5- nozzles, nozzle diameters 14mm, 16mm, 18mm, classifier has 3-wheels, each wheel with 60 vanes wide pitch, narrow pitch 120 vanes, max wheel speed 4000 rpm, each whees driven by 5.12 - 16 kw, 3/50/415 volt, 940/2940 rpm motor, (1) 1100 liter carbon steel feed hopper weld dished top, weld coned bottom, bottom outlet with 150mm diameter carbon steel screw conveyor, 15.1 rpm speed,
Hammer mill pulverizer with product heater with left hand drive Rated for 1200 rpm with 12 hammers Machine has auto oiler for bearings. With Spinner and blower to move sized product to plant. with spinner 22,565 lbs. Product heater is rated 6 mm BTU, CS, North American air dryer powered by natural gas With Blower, Gas train and heater installed on skid Skid dimensions are 193" long x 61" wide x 74" high Air inlet is rectangular flange 15" x 11". Air Outlet is round 19" diameter Complete automated fuel train by, with series 2300 turbo blower. Product air heater is also listed under IPP # 221294.
Ni-Resist, Micro Atomizer Atomizer set up in its own building complete with the following accessories: Feed hopper is 33" wide x 39" long, Super sack unloader with dust collector & bagger, 50 Sq.Ft., 304 SS baghouse with fan. Takes 30 socks 4" diameter x 6' long, Takes 30 socks 4" diameter x 6' long, 51" w x 52" d x 68" h chamber.
Atomizer air swept classifying pulverizer/mill, all parts which are in contact with the product are stainless steel, capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
Atomizer air swept classifying pulverizer/mill all parts which are in contact with the product are stainless steel, capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
400 to 1200 Lb./Hr., Aljet Roto-Jet mill system designed to grind particles sized from 0.5 to 45 microns. This 304 SS product contact system features all the equipment needed to get into operation immediately, including major equipment, controls, and all associated ductwork. Major components are as follows: One(1) Aljet Roto Mill, Model 30, serial # P-11737-E, 304 SS construction, with integral dynamic classifier. The mill is rated for up to 150 psi, from 40 degrees F to 100 degrees F. The Roto-Jet has opposing grinding nozzles, (4) 11mm in size. The jet mill requires 1800- 2300 scfm of clean air 70 degrees F at 100 psi. The classifier is a model 30 RJ rated for 2000 cfm with a maximum rpm of 3,500 rpm. The classifier is driven by a 30 HP AC motor, with adjustable speed. Adjusting the speed of the classifier controls the rate and particle size of the mill. One(1)Acrison feeder, 304 SS contact, screw type, that feeds product to the mill. It is a model FHM01206, # 749040, with an input HP of 1.5, and a ratio of 15:1. The variable speed drive motor is slaved to the speed of the classifier to control feed to the mill. One(1) exhaust fan, manufactured by American Fan Co., model # R-13403 handle the air movement through the system. Its constructed of carbon steel, and rated for 2017 CFM at 60” SP. This fan is driven by a Siemens AC motor rated for 30 HP at 3600 rpm, and requires 60 hz/3ph/230-460 volts. The frame size is 286TS and its a TEFC motor. One(1) dust collector manufactured by Sly, handles the chore of keeping things de-dusted. The dust collector is 304 SS for product contact and the plenum, and has 432 Sq. Ft. of filtration area. It contains (36)- 16 oz. cloth filters with cages, 5.75” diameter x 6’ long. The air to cloth ratio is 2.89:1. This duct collector also has a 18” x 36” explosion door and fire suppression can be added. The system includes all controls, rotary air locks, and ductwork to set up the machine. The footprint of this machine requires the approximate size of 23' wide x 10' deep x 20' high.
Hammer mill pulverizer with product heater with left hand drive Rated for 1200 rpm with 12 hammers Machine has auto oiler for bearings. With Spinner and blower to move sized product to plant. Weight on hammer mill 14,660 lbs with spinner 22,565 lbs. Product heater is rated 6 mm BTU, CS, North American air dryer powered by natural gas With Blower, Gas train and heater installed on skid. Skid dimensions are 193" long x 61" wide x 74" high. Air inlet is rectangular flange 15" x 11". Air Outlet is round 19" diameter Complete automated fuel train by, with series 2300 turbo blower. Product air heater is also listed under IPP # 221295.
Atomizer air swept classifying pulverizer/mill parts which are in contact with the product are stainless steel capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
Pressure shock resistant design
Rated for 1500 kg./Hr,
pressure 11 bar at 70 degrees C,
side bottom inlet 390mm diameter and 125mm diameter,
top discharge 340mm,
36 pin disk underdriven by 45kW, 3/60/460 volt, 1775 rpm IP65 motor,
24 blade classifier under driven by 11kW, 3/60/460 volt, 1760 rpm motor,
Classifier is rated max. 3100 rpm.
speed 720 to 1775 rpm.
400mm air intake nozzle,
hinged top cover with manually operated opening mechanism
Coffee grinder
Mikro Atomizer Rated for 6,000 rpm. Capable of handling capacities from 100 to 1000 lbs/hr, dependent on the material, this machine handles 3 functions in one machine. Pulverizes, air classifies and conveys the material.
rated: 11 DCuM, 0.05 bar, 60°C., 10 bar overpressure stud disc diameter: 315 mm, plate beater: 298 mm, swing beater: 298mm, air inlet: DN 100 mm
oscillating granulator. milling chamber 370 mm wide x 550 mm long 3~ 380V/220V 2,7A/4,7A 1,1 kW; 50Hz completely enclosed in stand
Ni-resist micro-atomizer Exhaust manifold y-connection to baghouse. Separating wheels stellite, SS hammers. 3/60/230/460 volt Feeder belt driven.
Used pulverizer equipment from IPP encompasses a wide range of machinery essential for material size reduction and processing. Whether you require hammer mills, jet mills, or fluid energy mills, IPP offers equipment that meets your specific needs. With over 47 years of industry experience, IPP supplies used, surplus, and secondhand pulverizer equipment from 20 global plant sites and maintains a ready-to-ship inventory of 15,000+ process systems.
IPP stocks equipment from leading manufacturers such as Mikro Pulverizer, Fitzpatrick, and Hosokawa, ensuring quality and reliability.
To ensure durability and compliance, pulverizer equipment is typically constructed from:
