horizontal, twin paddle mixer SO # C-l6001 with 10 Gauge covers and flat top with 3 "V" belt sheeves through a Dodge single reduction torque arm. Torque arm # T-17 Capable of continuosly handling 48,000 lbs/hr.
Type: Mixer-Ribbon & Paddle
Manufacturer: Patterson Kelly
Condition: Used
Material: Stainless Steel 304
Design Capacity: 12.7 m3 (450 ft3)
Operating Capacity: 8.5 m3 (300 ft3)
cylindrical slurry blender, Has single shaft agit w/approx (12) paddle arms. Sprocket for chain drive, takes 25 HP. Openings: top 2-12", 2-10", 2-2"; heads 2-20"; 1-6" and 1-2" outlet.
Ribbon Type: Paddles.
Type: Mixer-Ribbon & Paddle
Model: U-700
Condition: Used
Material: Stainless Steel 304
Design Capacity: 1.5 m3 (53 ft3)
Operating Capacity: 1 m3 (35.3 ft3)
stainless steel ribbon blender. Chamber 60" long x 38" wide x 51" deep, Packing glands. Bolt flat top w/17" x 12" hinged manway. Openings: top 3-9"; btm 1-5" w/valve. worm and worm wheel.
Ribbon Type: Interrupted ribbon. Agitation Shaft Sealing: Packing.
Type: Mixer-Ribbon & Paddle
Manufacturer: The Young Industries, Inc.
Model: 300L
Condition: Used
Material: Stainless Steel 304
Design Capacity: 8.5 m3 (300 ft3)
Operating Capacity: 7.8 m3 (275 ft3)
Ribbon Blender Size 300L, Single ribbon design, packing glands on shaft, removable ribbon design. Ribbon has a large sprocket on end of shaft for chain drive, no drive with unit. Blender trough is 60" wide x 144" long x 72" deep, with a bolted on SS cover The shaft measures 7 1/4" od.
Ribbon Type: Single Helix. Paddle/Ribbon MOC: Stainless Steel Other. Agitation Shaft Sealing: Packing.
Type: Mixer-Ribbon & Paddle
Manufacturer: Loedige Littleford Ploughshare
Model: KM8000
Condition: Used
Material: Stainless Steel 304
Design Capacity: 8 m3 (282.5 ft3)
Operating Capacity: 5 m3 (176.6 ft3)
continuous mixing 25,000 kg/hr 8000 liter(2113 gallon) total capacity with (2) side hatches with hinged covers and hand wheel swing bolts, (1) 16" x 24" ID top drive end charge port, (1) 16" ID vent port top center, and (1) 17" x 20" ID bottom end discharge port. Internal shaft with plows 3/60/230/460 volt 1750 rpm down to 90 rpm Weight 17,200 lbs.
Operational mode: Continuous. Ribbon Type: Plows.
