Used ribbon and paddle mixers for sale: proven blending for powders, granules and bulk solids
Highest-ranked available inventory for this selection.
Used ribbon and paddle mixers for sale: proven blending for powders, granules and bulk solids
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Showing 25 of 35 matching Ribbon & Paddle Mixers.
CS jacketed ribbon blender
Internal pressure rated 3 psi @ 200 deg. F to -20 deg. F min.
Jacket is rated 60 psi @ 200 deg. F to -20 deg. F min.
Blender configuration is full flat top cover with center bottom outlet.
Shaft has stuffing box, ribbon design is removable, continuous double ribbon with Teflon wipers
Shaft is driven through a Dodge shaft mounted reducer with a 24.7/1 gear reducer.
Top cover is clamp on removable design.
Top cover openings include 2-4", 1-8", 2-1", and 1 top feed/manway opening of 12"x16". Vessel is fully insulated.
Center bottom outlet is approx. 6" and discharges through a knife gate into a Young motorized 2-3 hp delumper.
ribbon mixers with cylindircal housing, ribbon agitator stuffing box weight motor 660 kg, inlet and outlet filters
jacketed Loedige ploughshare mixer with choppers machine #7644 behalter #1952 jacket pressure 0.5 bar @ 110 deg C (180ltr) chamber 1110mm diameter x 2960mm straight side, internal rotor with (10) plow blades and (2) end blades, blades are removable via a reduction gearbox, packed gland on shaft, c/steel jacket on straight side only. (4) 321 s/steel choppers each belt driven by a 2-speed motor 7.5 kw 3/50/230/460/380/420 volt, 2950 rpm or 8.5 kw, 3/60/440/480 volt, 3510 rpm (8) spray nozzles, openings top: 3-350mm, jacket: 6-50mm, straight side: 2-540mm wide x 400mm high inspection doors, 2-50mm (for probes), bottom: 3-300mm long x 200mm wide each with a pneumatic operated valve, 8-25mm (spray nozzles,
Jacketed, Carbon steel body and Jacket, 316 SS Clad internal(contact) Single Ribbon Mixer. with CS jacket. Packing glands on shaft, Chain drive with by approximately 30 HP motor and reducer.
Ribbon Blender Size 300L, Single ribbon design, packing glands on shaft, removable ribbon design. Ribbon has a large sprocket on end of shaft for chain drive, no drive with unit. Blender trough is 60" wide x 144" long x 72" deep, with a bolted on SS cover The shaft measures 7 1/4" od.
with cylindircal housing ribbon agitator stuffing box weight motor 660 kg, inlet and outlet filters, and documents
with cylindircal housing ribbon agitator motor : 500 V/78 A/50 Hz/1485 rpm weight motor 660 kg, inlet and outlet filters, and documents
jkt ribbon blender. Total capacity 2600 liter. Jkt rated 8 bar. 1470 rpm motor (no motor) 240 rpm input, 36 rpm output. Shaft 6" (150mm) dia. Openings: top 34" long x 16" wide, 1-9"; jkt 2-1", 4-1/2"; center btm outlet approx 8" dia w/pneumatically operated swing valve, discharging into chute 31" x 15". Fitted hinged full cover w/counter weight. Cover has vert charge hole approx 2'6" x 1'6" w/hinged cover.
Laboratory stainless steel Loedige mixer with one chopper and one door (150mm) for bottom discharge Motor: 220/380 V main V-belt drive data: 2.2 kW, 220/380 V, 50 Hz, 1.4200 rpm
125 liter bowl capacity, Bowl type mixer with clamped flat top and pneumatic assist for raising the lid, lid has a 6" latching inlet and a 2" sanitary quick fitting. Unit has a 5" sanitary, pneumatic flush valve on side bottom of bowl for discharge. Sanitary polished finish on both internals and exterior. Unit has a high intensity mixing blade in bottom of the bowl and a high speed chopper through side wall. Air purge seals on chopper. Electric connections are plug in, air line is a quick coupling. Controls are self contained with the unit.
jacketed Paddle Blender Rated for 50 psi at 300 degrees F 300 gallon liquid capacity. Scraped surface paddles.
continuous mixing 25,000 kg/hr 8000 liter(2113 gallon) total capacity with (2) side hatches with hinged covers and hand wheel swing bolts, (1) 16" x 24" ID top drive end charge port, (1) 16" ID vent port top center, and (1) 17" x 20" ID bottom end discharge port. Internal shaft with plows 3/60/230/460 volt 1750 rpm down to 90 rpm Weight 17,200 lbs.
ploughshare mixer with (4) side choppers
Job 167
Chamber is 1.5m I.D x 3370mm long
packed glands on shaft
shaft speed 74 rpm
2-speed motor
chopper direct driven by a 2-speed motor, 5.5 kw, 3/50/220/240/380/420 volt, 1450 rpm or 6.4 kw, 3/60/250/280/440/480 volt, 1750 rpm,
openings top: 4-250mm x 250mm with pneumatic slide valves, 1-150mm, side: 2-750mm x 620mm inspection doors, 4-25mm, center bottom: 1-350mm x 250mm with actuated valve
paddle mixer 36 rpm. paddle speed.Packed glands. Unit has bottom discharge with manual valve.
"L" Series ribbon blender Features: hinged lid, removable endplate, interrupted ribbon, external bearings, packing glands 220/250/380/440 volt 69.3 rpm Unit with a built-in on/off switch. Openings: inlet 18" x 9"; outlet 1-4" with manually operated 'V' Series discharge valve.
Shape: cylindrical Mixer type: ribbon mixer Ribbon type: un-interrupted Shaft seal: mechanical 3/50/380/660 volt 1440/205 rpm non-flameproof geared motor External bearings on shaft. Openings: top 19" x 18" inspection cover with 6" opening, 1-9" feed with hopper, 1-6"; straight side (2) 18" x 18" inspection doors; bottom 6" x 70" long hydraulic operated discharge. Unit with 316 stainless steel 34" diameter x 7" straight side x 36" cone feed hopper.
Type: Ribbon blender ribbon speed 158 rpm (max) 3/50/380/415 volt hinged top cover,
Blender type: Ribbon blender via gearbox hinged top cover
15000 liter 1.9m diameter x 5m straight side 400/415 volt 1477 rpm packed glands on shaft openings top: 3-498mm, side: 3-600mm x 550mm inspection doors, 2-90mm ( 1 with sampling device), bottom: 1-438mm x 438mm with manual slide valve (center)
ribbon blender with removable endplates external bearings, packing glands Ribbon speed 37 rpm
ribbon speed 158 rpm (max) 3/50/380/415 volt trough 1.2m long x 300mm wide x 350mm deep hinged top cover
horizontal, twin paddle mixer SO # C-l6001 with 10 Gauge covers and flat top with 3 "V" belt sheeves through a Dodge single reduction torque arm. Torque arm # T-17 Capable of continuosly handling 48,000 lbs/hr.
Used ribbon and paddle mixers are industry-standard solutions for mixing dry powders, granules, and other bulk solids. Whether you’re blending spice mixes, pharmaceutical powders, plastic additives or construction materials, these mixers offer reliable, repeatable results. With more than 47 years of process industry leadership, IPP supplies used, surplus and secondhand ribbon and paddle mixers from 20 global plant facilities and maintains a massive inventory of 15,000+ ready-to-ship systems.
IPP offers single- and double-ribbon designs, paddle agitators, and hybrid models from trusted manufacturers like Ross, Munson, American Process Systems, and Jaygo.
Built to meet diverse industrial needs, these mixers are available in:
Learn more about batch powder mixing technologies and ribbon mixer performance from Powder & Bulk Solids.
Browse the IPP inventory or contact IPP’s powder mixing experts to find the right used, surplus or secondhand ribbon or paddle mixer for your process. With equipment in stock and ready to ship, IPP helps you reduce costs, lead time, and production risk.
