Stainless Steel 316 Western Supply BHM Shell and Tube Heat Exchanger - IPP# 220162

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Western Supply

Model: BEM

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 299.1 m² (3,200 ft²)

Orientation: Horizontal

Pitch: 1.25" Triangular

Shell Pressure: 5.2 bar (75 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 5.2 bar (75 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 914 mm (36 in). Head Material: Carbon Steel. Length: 7,250 mm (286 in). Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: Straight Tube. Tube Number: 625. Tube Diameter: 3,450 mm (135 in). Tube Length: 6,100 mm (240 in). Capacity: 56,800 L (15,000 gallons).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Western Supply

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 160.4 m² (1,750 ft²)

Orientation: Vertical

4,690,000 BTU/Hr

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 92.8 °C (199 °F). Shell Material: Stainless Steel 304. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 92.8 °C (199 °F). Tube Material: Stainless Steel 304. Shell Diameter: 686 mm (27 in). Head Material: Carbon Steel. Length: 6,100 mm (240 in). Tube-side Passes: 4. Tube Number: 330. Tube Diameter: 25.4 mm (1 in). Tube Length: 6,100 mm (240 in). Tube Thickness: 1.52 mm (0.06 in).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Western Supply

Model: AEL

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 123.5 m² (1,350 ft²)

Orientation: Vertical

4,170,000 BTU/Hr.

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 92.8 °C (199 °F). Shell Material: Stainless Steel 304. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 92.8 °C (199 °F). Tube Material: Stainless Steel 304. Shell Diameter: 635 mm (25 in). Head Material: Carbon Steel. Length: 6,100 mm (240 in). Tube-side Passes: 4. Tube Number: 254. Tube Diameter: 25.4 mm (1 in). Tube Length: 6,100 mm (240 in). Tube Thickness: 1.52 mm (0.06 in).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Bramah Process Plant Ltd

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 25.8 m² (277.7 ft²)

Orientation: Horizontal

Tube side: 10.55 kg/cm2 @ 299 deg C Shell side: 10.55 kg/cm2 @ 399 deg C (2) c/steel flat heads

Shell Pressure: 10.3 bar (150.1 psi). Shell Temperature: 399 °C (750 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150.1 psi). Tube Temperature: 299 °C (570 °F). Tube Material: Stainless Steel 316. Shell Diameter: 350 mm (13.8 in). Head Material: Carbon Steel. Length: 6,050 mm (238.6 in). Tube-side Passes: 4. Tube Number: 72. Tube Diameter: 19 mm (0.75 in). Tube Length: 6,050 mm (238.6 in).
