Titanium Wilton Engineering Ltd Shell and Tube Heat Exchanger - IPP# 226234

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Wilton Engineering Ltd

Condition: Used

Material: Titanium

Clad: Yes

Heat Transfer Surface Area: 67 m² (721.2 ft²)

Orientation: Horizontal

Head type: (2) flat heads (possibly Titanium clad on carbon steel) Design code: SEC V111 DIV.1.1968 & TEMA 'R' 1968

Shell Pressure: 88 bar (1,276 psi). Shell Temperature: 350 °C (662 °F). Shell Material: Carbon Steel. Tube Pressure: 88 bar (1,276 psi). Tube Temperature: 307 °C (584.6 °F). Tube Material: Titanium. Shell Diameter: 507 mm (20 in). Head Material: Titanium. Tube Number: 140. Tube Diameter: 19 mm (0.75 in). Tube Length: 9,130 mm (359.4 in). Nozzle Schedule: openings tube side: 1 head with 2-150mm, 1 head with none, shell side: 1-100mm with (2) 25mm off shoots, 1-75mm with (2) 25mm off shoots.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Wilton Engineering Ltd

Condition: Used

Material: Titanium

Clad: Yes

Heat Transfer Surface Area: 67 m² (721.2 ft²)

Orientation: Horizontal

• Heads: (2) flat heads
• Design code: SEC V111 DIV.1.1968 & TEMA 'R' 1968

Shell Pressure: 88 bar (1,276 psi). Shell Temperature: 350 °C (662 °F). Shell Material: Carbon Steel. Tube Pressure: 88 bar (1,276 psi). Tube Temperature: 307 °C (584.6 °F). Tube Material: Titanium. Shell Diameter: 507 mm (20 in). Head Material: Titanium. Tube Diameter: 19 mm (0.75 in). Tube Length: 9,130 mm (359.4 in). Nozzle Schedule: openings tube side: 1 head with 2-150mm, 1 head with none, shell side: 1-100mm with (2) 25mm off shoots, 1-75mm with (2) 25mm off shoots,.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Wilton Engineering Ltd

Condition: Used

Material: Titanium

Clad: Yes

Heat Transfer Surface Area: 67 m² (721.2 ft²)

Orientation: Horizontal

Shell: Incolloy 825 expansion joint Heads: (2) flat heads Design code: SEC V111 DIV.1.1968 & TEMA 'R' 1968

Shell Pressure: 88 bar (1,276 psi). Shell Temperature: 350 °C (662 °F). Shell Material: Carbon Steel. Tube Pressure: 88 bar (1,276 psi). Tube Temperature: 307 °C (584.6 °F). Tube Material: Titanium. Shell Diameter: 507 mm (20 in). Head Material: Titanium. Tube Number: 140. Tube Diameter: 19 mm (0.75 in). Tube Length: 9,128 mm (359.4 in). Nozzle Schedule: openings tube side: 1 head with 2-150mm, 1 head with none, shell side: 1-100mm with (2) 25mm off shoots, 1-75mm with (2) 25mm off shoots, .

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Luwa SMS

Condition: Used

Material: Titanium

Heat Transfer Surface Area: 58.4 m² (629 ft²)

Orientation: Horizontal

pressure tube side 30 bar@ 200 degrees C (640 liter), shell side 10 bar @ 200 degrees C (540 liter) shell with expansion bellows (4) internal baffle plates (2) titanium hemispherical heads TUV certified

Shell Pressure: 10 bar (145 psi). Shell Temperature: 200 °C (392 °F). Shell Material: Stainless Steel 321. Tube Pressure: 30 bar (435.1 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Titanium. Shell Diameter: 700 mm (27.6 in). Head Material: Titanium. Length: 3,700 mm (145.7 in). Tube Number: 324. Tube Diameter: 25 mm (0.98 in). Tube Length: 2,500 mm (98.4 in). Tube Thickness: 1.2 mm (0.05 in). Nozzle Schedule: - Openings: - Tube side: (1) head with 1-100mm, (1) head with 1-100mm, 1-80mm - Shell: 2-100mm, 1-50mm.
