Type: Compressor
Subtype: Centrifugal
Manufacturer: Atlas Copco
Model: 1616 6551 80
Condition: Unused
Material: Carbon Steel
Compressor Type: Centrifugal
Air end compressor head Part # 1616 6551 GA55 GBD- part # 2901-0844-00.
Type: Compressor
Subtype: Centrifugal
Manufacturer: Clark
Model: 2M8-6
Condition: Used
Material: Carbon Steel
Compressor Type: Rotary
Inlet Pressure: 0.97 bar (14.1 psi)
4,079 acfm rotary air compressor Direct driven by a steam turbine (IPP# 212810) through a gear reducer (IPP# 212811) Pressure Suction 14.07 6400 rpm critical speed 12"" inlet X 10"" discharge Nozzle orientation is up
Discharge Pressure: 33.8 bar (490 psi). Flow Rate: 6,950 m3/h (4,100 CFM). Inlet Diameter: 304.8 mm (12 in). Speed (RPM): 10,211.
Type: Compressor
Subtype: Centrifugal
Manufacturer: Clark
Model: 4M8-7
Condition: Used
Material: Carbon Steel
Compressor Type: Centrifugal
Inlet Pressure: 2 bar (29 psi)
11,763 ACFM with seven impellers inlet temperature is 24 degrees F. The average compressibility factor is 0.979. The nozzle orientation up The compressor rpm is 5,875 rpm, with a maximum speed of 6,220 rpm and a first critical speed of 3,000 rpm. Compressor HP is 1,574. Designed to be driven by a steam turbine (IPP# 212817) with a speed increaser (IPP # 212818).
Discharge Pressure: 4.1 bar (60 psi). Flow Rate: 20,000 m3/h (11,750 CFM). Speed (RPM): 6,220.
Type: Compressor
Subtype: Centrifugal
Manufacturer: Clark
Model: 2M8-5
Condition: Used
Material: Carbon Steel
Compressor Type: Centrifugal
Inlet Pressure: 9.7 bar (140 psi)
4284 ACFM Rated for 9185 hp Pressure Suction 140 Nozzle orientation up. Rpm 10483 Driven by a steam turbine (IPP# 212817) and speed increaser (IPP # 212818). Molecular weight, 17.03 5 Stages, 10,438 rpm speed. 6650 critical speed. MAWP rated for 450 psi at 385 degrees F.
Discharge Pressure: 15.9 bar (230 psi). Flow Rate: 7,300 m3/h (4,300 CFM). Speed (RPM): 11,000.
