750/2000 liter fluidizing intensive mixer/cooler system Mixer Mdl 750-4 cooler mixer Mdl 2000-2 Mixer/heater is 780 liter total capacity, 600 liter working capacity. Shell 1.0m dia. Load 235 Kg. W/200mm discharge valve. W/double jkt for heating and cooling rated 0.05 MPa mixer blades output speed 450/900 rpm. Motor type AHR355-8/4. Mixer/cooler is 2000 liter total capacity, 1600 liter working capacity. Load 580 kg. W/jkt for cooling. Shell 1.8m dia. W/300mm dia discharge valve. Driven by 18.5 KW, 3/50/380 volt, 1460 rpm motor, 75 rpm output speed. W/side entering chopper, driven by 11.0 KW, 3/50/380 volt, 1790 rpm motor.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MSHK750/2000
Condition: Unused
Material: Stainless Steel 304
Capacity (Design): 780 L (206.1 gallons)
Motor Power: 105 kW (140.8 HP)
750/2000 liter fluidizing intensive mixer/cooler system. Mixer Mdl 750-4, cooler mixer Mdl 2000-2. Mixer/heater is 780 liter total capacity, Shell 1.0m dia. Load 235 Kg. W/200mm discharge valve. W/double jkt for heating and cooling rated 0.05 MPa. mixer blades output speed 450/900 rpm. Motor type AHR355-8/4. Mixer/cooler is 2000 liter total capacity, 1600 liter working capacity. Load 580 kg. W/jkt for cooling. Shell 1.8m dia. W/300mm dia discharge valve. Driven by 18.5 KW, 3/50/380 volt, 1460 rpm motor, 75 rpm output speed. W/side entering chopper, driven by 0.55 KW, 3/50/380 volt, 1790 rpm motor.
Bowl Diameter: 1,000 mm (39.4 in). Bowl Depth: . Blade Speed (RPM): 900. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MSH750.4-S
Condition: Unused
Material: Stainless Steel 304
Capacity (Design): 750 L (198.1 gallons)
Motor Power: 22 kW (29.5 HP)
jacketed Trusioma high intensive mixer Aluminum cover Mixer max 450 rpm. Max working capacity 300 liter. 2-tier, 2-blade impellors with baffle. Hinged cover with pneumatic opening. 8" pneumatic discharge valve. switch gear cabinet.
Blade Type: 2 tier 2 blade w/ baffle. Bowl Jacket: Yes. Controls: Yes.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MVA-1000R
Condition: Unused
Material: Stainless Steel 316
Capacity (Design): 1,000 L (264.2 gallons)
Motor Power: 30 kW (40.2 HP)
Trusioma high intensive mixer. Jacket rated 0.05 mPA. 2-tier 2-blade impellor. Total volume 1.0 cu M. Approx working capacity 400 to 600 liters. Top bolt cover with 1/3 hinged opening. 28-40 HP (22 to 30 KW), 3/50/220/380 volt, 740 to 1480 rpm XP motor thru gear reducer. Bowl 44.5 to 87 rpm. 200mm outlet w/manul gate valve.
Bowl Diameter: 1,440 mm (56.7 in). Bowl Speed (RPM): 87. Blade Type: 2-tier 2-blade. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Petzholdt
Model: PKM4800
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 4,800 L (1,268 gallons)
Motor Power: 55 kW (73.8 HP)
jacketed high intensity mixer/disperser/homogenizer/emulsifier Double jacketed for heating and cooling Underdriven Top openings for liquid and powder feed Cover opens with a pneumatic operated cylinder. 120mm side bottom discharge with pneumatic operated valve
Bowl Diameter: 2,500 mm (98.4 in). Bowl Depth: 1,410 mm (55.5 in). Bowl Jacket: Yes.
