jacketed Trusioma high intensive mixer
Aluminum cover
Mixer max 450 rpm.
Max working capacity 300 liter.
2-tier, 2-blade impellors with baffle.
Hinged cover with pneumatic opening. 8" pneumatic discharge valve.
switch gear cabinet.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MSHK750/2000
Condition: Unused
Material: Stainless Steel 304
Capacity (Design): 780 L (206 gallons)
Motor Power: 105 kW (141 HP)
750/2000 liter
fluidizing intensive mixer/cooler system
Mixer Mdl 750-4
cooler mixer Mdl 2000-2
Mixer/heater is 780 liter total capacity, 600 liter working capacity.
Shell 1.0m dia.
Load 235 Kg.
W/200mm discharge valve.
W/double jkt for heating and cooling rated 0.05 MPa
mixer blades output speed 450/900 rpm.
Motor type AHR355-8/4.
Mixer/cooler is 2000 liter total capacity, 1600 liter working capacity.
Load 580 kg.
W/jkt for cooling.
Shell 1.8m dia.
W/300mm dia discharge valve.
Driven by 18.5 KW, 3/50/380 volt, 1460 rpm motor, 75 rpm output speed.
W/side entering chopper, driven by 11.0 KW, 3/50/380 volt, 1790 rpm motor.
Bowl Diameter: 1,000 mm (39.4 in). Blade Speed (RPM): 900. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MSHK750/2000
Condition: Unused
Material: Stainless Steel 304
Capacity (Design): 780 L (206 gallons)
Motor Power: 105 kW (141 HP)
750/2000 liter
fluidizing intensive mixer/cooler system.
Mixer Mdl 750-4, cooler mixer Mdl 2000-2.
Mixer/heater is 780 liter total capacity,
Shell 1.0m dia.
Load 235 Kg.
W/200mm discharge valve.
W/double jkt for heating and cooling rated 0.05 MPa.
mixer blades output speed 450/900 rpm.
Motor type AHR355-8/4.
Mixer/cooler is 2000 liter total capacity,
1600 liter working capacity.
Load 580 kg.
W/jkt for cooling.
Shell 1.8m dia.
W/300mm dia discharge valve.
Driven by 18.5 KW, 3/50/380 volt, 1460 rpm motor, 75 rpm output speed.
W/side entering chopper, driven by 0.55 KW, 3/50/380 volt, 1790 rpm motor.
Bowl Diameter: 1,000 mm (39.4 in). Bowl Depth: 300 mm (11.8 in). Blade Speed (RPM): 900. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MVA-1000R
Condition: Unused
Material: Stainless Steel 316
Capacity (Design): 1,000 L (264 gallons)
Motor Power: 30 kW (40.2 HP)
Trusioma high intensive mixer.
Jacket rated 0.05 mPA. 2-tier 2-blade impellor.
Total volume 1.0 cu M.
Approx working capacity 400 to 600 liters.
Top bolt cover with 1/3 hinged opening.
28-40 HP (22 to 30 KW), 3/50/220/380 volt,
740 to 1480 rpm
XP motor thru gear reducer.
Bowl 44.5 to 87 rpm.
200mm outlet w/manul gate valve.
Bowl Diameter: 1,440 mm (56.7 in). Bowl Speed (RPM): 87. Blade Type: 2-tier 2-blade. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Petzholdt
Model: PKM4800
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 4,800 L (1,268 gallons)
Motor Power: 55 kW (73.8 HP)
jacketed high intensity mixer/disperser/homogenizer/emulsifier
Double jacketed for heating and cooling
Underdriven
Top openings for liquid and powder feed
Cover opens with a pneumatic operated cylinder. 120mm side bottom discharge with pneumatic operated valve
Bowl Diameter: 2,500 mm (98.4 in). Bowl Depth: 1,410 mm (55.5 in). Bowl Jacket: Yes.
