REBUILT Internal volume 3890 liters, jacket volume 267 liters. The filter has the ability to tilt for discharge and ease of cleaning or screen change. With jacketed perforated filter plate, mounted on wheels and clamped to filter vessel, vessel mounted in A-frame stands Raker lifted and shell tumbled with oil hydraulic system with Kracht powerpak, approx 3 HP motor. With new manual ATEX XP controls.
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Charles Thompson
Model: CT-2525
Condition: Used
Material: Stainless Steel 316
Filtration Area: 5 m² (53.8 ft²)
Diameter: 2,500 mm (99.4 in)
agitated jacketed pressure filter/dryer 400mm agitator stroke, 400mm product discharge lateral, 15 rpm agitator speed, Zone 2 IIB T3 classification internal wash ring (pipe), clamped flat filter bed with hydraulic raise/lower mechanism and castors for removing, valve and filter bed raise/lower mechanism driven by a power pack, power pack with a 3kw, 3/50/415 volt, 1440 rpm CE IP55 Ex NII T3 motor,
Pressure: 4 bar (58 psi). Temperature: 150 °C (302 °F). Jacket: Yes. Jacket Pressure: 4 bar (58 psi). Jacket MOC: Carbon Steel. Jacket Temperature: 150 °C (302 °F).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Rosenmund
Model: RPD 8-398-86
Condition: Used
Material: Stainless Steel 316
Filtration Area: 8 m² (86.1 ft²)
Diameter: 3,250 mm (128.3 in)
center bottom discharge design internal pressure -1/3 bar @ -15/165 deg C; jacket -1/5 bar @ -15/165 deg C. Non-cored shaft Designed for cake thickness 500 mm Vessel is 13200 liter volume jacket volume is 75 liters
Pressure: 3 bar (43.5 psi). Temperature: 165 °C (329 °F). Jacket: Yes. Jacket Pressure: 5 bar (72.5 psi). Jacket Type: Half Pipe/Limpet. Jacket Temperature: 165 °C (329 °F).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Rosenmund
Model: RPD 8-398-86
Condition: Used
Material: Stainless Steel 316
Filtration Area: 8 m² (86.1 ft²)
Diameter: 3,250 mm (128.3 in)
CODAP 85, center bottom discharge design Non-cored shaft internal pressure -1/3 bar @ -15/165 deg C;, jacket -1/5 bar @ -15/165 deg C With 316L (1.4435) stainless steel half pipe coil jacket on straight side cover with a shroud Designed for cake thickness 500 mm Vessel is 13200 liter volume Includes hydraulic controls and vacuum pump skid.
Pressure: 0.21 bar (3 psi). Temperature: 73.9 °C (165 °F). Jacket: Yes. Jacket Pressure: 5 bar (72.5 psi). Jacket Type: Half Pipe/Limpet. Jacket Temperature: 165 °C (329 °F).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Rosenmund
Model: RPD 8-398-86
Condition: Used
Material: Stainless Steel 316
Filtration Area: 8 m² (86.1 ft²)
Diameter: 3,250 mm (128.3 in)
Codap85
center bottom discharge design
Includes hydraulic controls and vacuum pump skid.
316L stainless steel half pipe coil jacket on straight side cover with a shroud
jacket volume is 75 liters.
jacket -1/5 bar
Non-cored shaft.
Rated: internal pressure -1/3 bar
Designed for cake thickness 500mm.
Vessel is 13200liter volume
Includes hydraulic controls and vacuum pump skid
Pressure: 3 bar (43.5 psi). Temperature: 165 °C (329 °F). Jacket: Yes. Jacket Pressure: 5 bar (72.5 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 316. Jacket Temperature: 165 °C (329 °F).
