• mobile laboratory filter/dryer with tilting mechanism,
• design pressure internal 1 bar + full vacuum @ -20/150 degrees C, jacket: 6 bar + full vacuum @ -20/150 degrees C,
• all wetted parts are Hastelloy C22,
• 50 liter slurry capacity,
• 20 liter cake capacity,
• 350mm diameter x 680mm straight side,
• 6-30rpm shaft speed,
• agitator driven by 1.5kW, 3/50/230/400 volt, 1420 rpm CE ATEX EExd IIB T4 IP55 motor,
• hydraulic driven agitator raise/lower mechanism with powerpack,
• alloy 22 bellows on shaft,
• flat bottom filter plate with mesh filter and can be rotated for cleaning,
• manual vessel tilt mechanism,
• strip sight glass on side for measuring cake depth,
• approx 100mm side discharge which is fully contained in a glovebox,
• all mounted on stainless steel frame with wheels for full mobility,
• design code ASME VIII DIV 1 (1998) + A '00'
• Can be used with 248331 APOVAC system for vacuum at an additional cost.

• Side bottom discharge with automatic valve Agitator Cored for Heating/Cooling: Yes. Vessel Liquid Capacity: 400 gallons.

Alloy C22

Internal finish is a sanitary polish. 304SS sheathing. 304 stainless steel

18.35" Side discharge with discharge valve, 132 gallon Hastelloy C 22 side discharge valve. National Board # 287. rated FV/88 @392 degrees F.

Dryer Dimensions: 90" diameter x 76" length

hydraulic skid. Includes: integral Stock # 241013- Hastelloy C22 pulse jet Dust collector. 8.6" handhole, 4.33" site glass.

(Wetted parts) filter/dryer system dryer base jacket -1/16 bar @ -25/160 degrees C nominal volume of cake 2400 liter shaft is cored for steam heating gas type double mechanical seal shaft with Hydraulic raise/lower mechanism driven by a hydraulic power pack with a 2.2 kW, 3/50/400 volt 1450 rpm IP55 EExde IIB T4 motor side discharge with hydraulic valve fixed bed design with internal sintered mesh filter bed sampling point/outlet design code: AD 2000 Regelwerk PED 97.23/CE (1) 2 square meter top mounted Hastelloy C22 jacketed reverse jet dust filter, design design pressure internal -1/3.2 bar @ -25/160 degrees C 9230 liter), jacket -1/16 bar @ -25/160 degrees C (24 liter), 316L stainless steel jacket, (1) 1000 Nm3/hr COMBIVAC/APOVAC WKP1000/S/PMZE 2510 D6X6/APO 3.2/80/GK1.8 vacuum pump skid with booster pump, manufactured by NCB Gas Processing, asset #10006707 (1) 220 Nm3/hr liquid ring vacuum pump type WKP-4000-AD, 19kw motor, design pressure 100 mbar, (1) 3.2 square meter liquid ring cooler, (1) 1.8 square meter exhaust gas cooler, (1) 80 liter liquid ring tank, all mounted on a carbon steel skid, (1) 1000 Nm3/hr (working) booster pump, type WKP 4000 AD, serial #21170167, manufactured by Pfeiffer Vacuum, 6075m3/hr (max), 4500 rpm (max), pressure 100mbar, driven by 18.5/21kW, 3/50-60/690-400/660-380/415-440 VOLT, 2934/2924/3524 RPM ATEX EEx de IIB T4 IP55 motor,

Internal working pressure 90 psi and full vacuum @ -20/+450 degree F, jacket 150 psi @ -20/+450 degree F.Filter plate 150 psi @ -20/+450 degrees. F,total volume 150 gallon, max solids volume 47.5 gallon, stroke pressure shovels 12", 316L stainless steel filterplate304L stainless steel jacket. Paddle speed approx 5-35 rpm, packed gland on shaftAgitator raise and lower mechanism driven by same powerpak. Center bottom discharge with hydraulic valve. Heated filter perforated plate with hydraulic lowering ramMax capacity vessel 17 cubic feet, jacket 1.9 cubic feet, filter plate 0.3 cubic feet, built on control panel with agitator speed control, raise/lower speed control, counter pressure control, discharge tube open/close switch, base open/close switch, pressure gauge, and emergency stop button. Fabricate under license from Rosenmund by Gaston County. Gaston County serial # F80019-588-1.

• Can be used with 248331 APOVAC system for vacuum at an additional cost.

• agitated pressure Nutsche filter,
• design pressure internal -1/3.2 bar @ -10/200 degrees C (22400 liter),
• jacket -1/10 bar @ -10/200 degrees C (170 liter),
• filter base jacket 6 bar @ -10/200 degrees C (407 liter)
• 6000 liter nominal cake volume
• 500mm cake height
• fixed bed design with 316L stainless steel filter mech
• center bottom discharge via plunger that runs down the center of the shaft,
• shaft driven by 37/42kw 3/50-60/690-400/660-380/415-440 volt 1480/1478/1482/1778 rpm EEx de IIB T4 ATEX motor via a 253.356:1 ratio reduction gearbox,
• Packed gland
• shaft speed 2.7-8.2 rpm,
• shaft with Hydraulic raise/lower mechanism, driven by a hydraulic power pack with 2.2kw, 3/50/380 volt, 1500 rpm EEx de IICT4 motor,
• internal wash ring/spray bar,
• side inspection manway with cover and davit,

(1) centrifugal pump, driven by 11/12.5kW 3/50-60/690-400/660-380/415-440 volt, 2936/2929/2942/3526 rpm, EEx de IIB T4 ATEX motor, mounted on a baseplate

• Certified by Chaudronnerie Des Roches (France).
• Jacketed on straight side only.
• EX Proof Controls
• AC drive motor on hydraulic unit for moving the agitator shaft up and down: Reliance Duty Master AC. 1.5 HP, 1155 rpm Frame 182TD, UL listed3 phase 60 Hz, 230/460 v. Direct mounted to the top of the hydraulic tank.
• Can be used with 248331 APOVAC system for vacuum at an additional cost.

Filter interior is polished to a mirror polish (220 grit)With cored and heated shaftshaft rated for 87 psi at 208 degrees F.Hydraulic driven agitator rotation 1:14 from 6-58 rpm.With stuffing box agitator seal with gas purge. Hydraulic power pack operates the following.Agitator up/down, Bottom openingtiltingand the hatchPower pack is driven by a Reliance 10 hp 460volt, 3 ph motorSide solids dischargelamped bottom for heads removalTilting type filterWith 316 SS base and cabinetexterior parts polished to an 80 grit finishAll gaskets are PTFE.Filter has washing nozzles, and Explosion proof lighting for filter interiorAlso included is a Rosenmund Apovac Vacuum systemincluding vacuum pump and ring -Liquid vessel and coolerApovac model 1.5/660 PMSH 156 D2Serial # 51 050with Vacuum pump by Gepruft With PLC control systemhas operators controls mounted on hydraulic station

• Can be used with 248331 APOVAC system for vacuum at an additional cost.

• Shell rated 88.5/FV psi @392 Deg F. Jacket 316SS, rated 152.5/FV @392 Deg F Vertical Filter
• Dryer Dust collector Jacket rated FV 152 @392degrees F. Internal finish is a sanitary polish. 304SS sheathing Mechanical seals. Cored shaft with . Side discharge with side discharge valve .integral Stock # 241129- Hastelloy C22 pulse jet Dust collector. Dryer Dimensions: 90" diameter x 76" length132 gallon Hastelloy C 22 side discharge valve. rated FV/88 @392 degrees F

CODAP 85, center bottom discharge design Non-cored shaft internal pressure -1/3 bar @ -15/165 deg C;, jacket -1/5 bar @ -15/165 deg C With 316L (1.4435) stainless steel half pipe coil jacket on straight side cover with a shroud Designed for cake thickness 500 mm Vessel is 13200 liter volume Includes hydraulic controls and vacuum pump skid.

agitated vacuum nutsche filter internal pressure -1/4 bar @ -10/100 degrees C, 9000 liter internal washing/spray bar clamped flat filter base mounted on castors for removal side discharge with valve driven by a hydraulic power pack driven by 22kW/3~/50Hz/500V/1.480rpm EEx motor via a Flender reduction gearbox

jacketed agitated Nustch filter/dryer 2800 liter, s/steel half pipe coil jacket 69 liter total volume clamp bottom type HYS 2327, Serial number 221316, 500 Y-Exi,, 24V-Ex, FD072, 0, 577624/691. Packing gland on shaft

agitated jacketed pressure filter/dryer 400mm agitator stroke, 400mm product discharge lateral, 15 rpm agitator speed, Zone 2 IIB T3 classification internal wash ring (pipe), clamped flat filter bed with hydraulic raise/lower mechanism and castors for removing, valve and filter bed raise/lower mechanism driven by a power pack, power pack with a 3kw, 3/50/415 volt, 1440 rpm CE IP55 Ex NII T3 motor,

• APOVAC system skid mounted.

• 80 CFM 2.2 GPM with a Sulzer Burkhardt Vacuum Pump, typically contains two heat exchangers and a receiver.

• All on a skid mounted system.

• Can be used with the following IPP stock numbers: 247646, 247146, 247050, 209158, 230453, 705428, 706865, 248105, & 247051

• Receiver is 316 L SS, 20 Gallon, 18" diameter x 18" straight side, rated for FV/60 psi at 248 degrees F.

• Heat exchanger serial # W8788C, 10 Sq. Ft., 316L SS tubes, tube sheets, heads and shell. Shell rated for FV90 psi at 248 Degrees F., tubes rated for FV 60 psi at 248 degrees F.

  31 straight tubes, 0.75" diameter x 18 GA x 22" long.

• Heat exchanger, serial # W8788B, 202 Sq.Ft. 316L SS tubes, tube sheets, heads and shell. Shell rated for FV90 psi at 248 Degrees F., tubes rated for FV 60 psi at 248 degrees F.

  31 Straight tubes, 1" diameter x0.065" x 25" long.

REBUILT Internal volume 3890 liters, jacket volume 267 liters. The filter has the ability to tilt for discharge and ease of cleaning or screen change. With jacketed perforated filter plate, mounted on wheels and clamped to filter vessel, vessel mounted in A-frame stands Raker lifted and shell tumbled with oil hydraulic system with Kracht powerpak, approx 3 HP motor. With new manual ATEX XP controls.

• Rated 50/FV PSIG @ -20 to 370 degrees F internal; 150 PSIG @ -20 to 370 degrees F in the 316SS 1/2Vessel capacity rated 2000 gallon Unit includes a 22" diameter Rotary Gate Valve, Model-SS24, 22.5 diameter opening Bottom discharge.

Agitated Pressure FilterThe 24.5 Liter vessel is rated -1/6 Bar @ -20 to 200 degree CThe 2.7 Liter jacket is rated -1/6 Bar @ -20 to 200 degree C. The .3 Liter Heated Base is rated -1/6 Bar @ -20 to 200 degree C.With Bergmann mechanical seal on shaft, and CIP ports with spray balls for cleaningSide bottom solids discharge with manual flush valve, center bottom fluid outlet with manual ball valve. Clamped bottom head for removing heals. Comes with portable hydraulic power pack, that utilizes a piston pump for up/down and right/left agitator movement. Power pack has AB electric controlsFilter housing is mounted on a stainless steel frame with castors, and the hydraulic power pack is also on castors, making the entire unit portable.

• Can be used with 248331 APOVAC system for vacuum at an additional cost.

Pressure Nutsche Filter Racker lift driven by 0.37 kW 3/50/380 V motor. Cake thickness 600 mm. Equipped with CIP spray ring on top of filter body.

internals and shaft are highly polished 316 stainless steel Registration number: 1884 ATEX, II2G EEx de IIC T4 motor via a reduction gearbox, internal bellows on shaft shaft with rotary union joint agitator drive with hydraulic raise and lower mechanism, EagleBurgmann mechanical seal type SECCOMIXR5L-D40/94-E1, Ex II2GebT3 & ExII2DcbT195-C side discharge with hydraulic driven valve

316 stainless steel jacket on straight side and bottom filter bed internal spray bar insulated and 304 stainless steel clad mounting ring, power pack for raise/lower mechanisms/valve is unavailable

Side cake discharge Carbon steel straight jacket on side only The agitator raise/lower mechanism driven by 2.2/2.5 kw, 3/50/60 Hz, 220-240/380-415/440-480 volt, 1435/1735 rpm 2-speed motor Carbon steel straight jacket on side only The filter bed has a hydraulic raise/lower with a powerpac driven by 5.5 kw Side cake discharge has a hydraulic flush valve

center bottom discharge design internal pressure -1/3 bar @ -15/165 deg C; jacket -1/5 bar @ -15/165 deg C. Non-cored shaft Designed for cake thickness 500 mm Vessel is 13200 liter volume jacket volume is 75 liters

• Agitated jacketed Rosenmund filter dryer
• Batch size 20 to 25kg
• internal design pressure 0.39 MPa (3.9 bar) + vacuum @ -20/170 degrees C (120 liter)
• coil jackets 0.6 MPa (6 bar) @ -20/170 degrees C (10 liter)
• internal working pressure 0.15 MPa (1.5 bar) @ 100 degrees C
• jacket 0.6 MPa (6 bar) @ 100 degrees C
• 550mm diameter x 828mm from agitator opening to filter plate,
• chamber insulated and with 316L stainless steel cladding, side discharge with 316L stainless steel glove box
• Ex motor,
• filter plate has a raise/lower and a hydraulic lock mechanism driven by the same power pack,
• CE certified,
• unit also includes
• (1) stainless steel condenser, (1) stainless steel tank, (1) heating controller
• Can be used with 248331 APOVAC system for vacuum at an additional cost.

• mobile filter/dryer with tilting mechanism,
• designed by GL Filtration Ltd, manufactured by RMF Engineering Ltd,
• design pressure internal 6 bar + full vacuum @ -25/160 degrees C,
• jacket 6 bar + full vacuum @ -25/160 degrees C,
• all wetted parts are Hastelloy C22 with 0.6um polish,
• Hazard area classification Zone 1 IIB T4,
• 50 liter slurry capacity,
• 20 liter cake capacity,
• 350mm diameter x 665mm straight side,
• agitator driven by 1.1kW, 3/50/230/400 volt, 1400 rpm CE ATEX Ex II2G motor,
• hydraulic driven agitator raise/lower mechanism with power pack,
• alloy 22 bellows on shaft,
• flat bottom filter plate with Hastelloy C22 'PORSTAR' 22 micron filter media and can be rotated for cleaning,
• manual vessel tilt mechanism,
• strip sight glass on side for measuring cake depth,
• 150mm side discharge which is fully contained in a glovebox,
• all mounted on stainless steel frame with wheels for full mobility,
• design code: ASME VIII DIV 1 2007 + 'U' stamp,

pressure nutsche filter Cake thickness 400 mm Filter plate is mounted on casters. SEW Usocome gear reducer type FHF 100P. Packing gland on shaft. Hydraulic lift of agitator driven by 0.75 kW 3/50/220/440 V, 1350 RPM motor

316 stainless steel agitated jacketed pressure Nutsche filter Filter volume 7200 liters Drive manufactured by Von Roll, Type CRG5 Hydraulic racker lift driven by 0.75 HP, 3/50/500 volt, 1450 rpm motor. Packing gland on shaft
