Available Evaporators

Showing 25 of 37 matching Evaporators.

Stock Number: #221539
Evaporation Rate: 320 lb/h
Total Heat Transfer Surface Area: 6 m²
Orientation: Horizontal
Diameter: 1,200 mm
Height: 3,100 mm
Pressure: 6.4 bar
Temperature: 350 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: Loher DNGW-225MB-08A
Additional Information: thin film evaporator jacket -1/1.1 bar @ 350 deg C (110ltr) 316L s/steel (1,4404) chamber, c/steel jacket on straight side only, 316L s/steel rotor, Crane 109 double mechanical seal with lubricator, speed 191 rpm, belt driven by 22kw, 3/50/380 volt, 730 rpm motor
More Details ⟶
Stock Number: #70260
Evaporation Rate: 590 lb/h
Total Heat Transfer Surface Area: 11 m²
Orientation: Horizontal
Diameter: 33.5 in
Height: 189 in
Pressure: 0.5 bar
Temperature: 220 °C
Vacuum: Yes
Additional Information: Jkt rated 13 bar @ 220 deg C Shell 850mm (34") dia x 4800mm (15.8') long, Rotor driven by 30 KW, 3/50/380 volt, 260 rpm output speed.
More Details ⟶
Stock Number: #233690
Evaporation Rate: 460 lb/h
Total Heat Transfer Surface Area: 91.8 ft²
Orientation: Horizontal
Pressure: 16 psi
Temperature: 662 °F
Vacuum: Yes
Drive Type:
Additional Information: Shell rated at FV/16 psi at 662 degrees F. jacket rated at FV/93 psi at 662 degrees Sako Thin Film type. Stainless steel rotor. Requires 40 HP drive system.
More Details ⟶
Stock Number: #81577
Evaporation Rate: 340 lb/h
Total Heat Transfer Surface Area: 67.8 ft²
Diameter: 660 mm
Height: 1,950 mm
Temperature: 140 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Additional Information: jacket rated 3 ATU @ 140 deg C Entrainment separator 900mm diameter x 1057mm long. Rotor speed 350 rpm. Mechanical seal on shaft. no V-belt motor. Conical section 730mm long
More Details ⟶
Stock Number: #102561
Evaporation Rate: 25 lb/h
Total Heat Transfer Surface Area: 5.4 ft²
Orientation: Vertical
Diameter: 6 in
Height: 72 in
Temperature: 392 °F
Vacuum: Yes
Additional Information: jkt rated 16 kg/sq cm @ 200 deg C. 9 gal capacity W/(2) rows of str blades and (2) rows of positive pitched blades @ 25 deg angle on central core. Driven by 20 HP, 1170 rpm Reeves variable speed drive, 6.2:1 ratio, 64 rpm min, 428 rpm max. C-configuration. Has air operated valve positioner w/mech seal. Has jkt btm cone; rotor extension (removable product propelling rotor section).
More Details ⟶
Stock Number: #706885
Evaporation Rate: 615 lb/h
Total Heat Transfer Surface Area: 11.5 m²
Orientation: Vertical
Diameter: 750 mm
Height: 4,850 mm
Pressure: 3.2 bar
Temperature: 200 °C
Jacket Pressure: 7 bar
Jacket Temperature: 200 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: Loher ANGA-225ME-04M
Additional Information: jacketed thin ‘filmtruder’ evaporator system, internal pressure -1/3.2 bar @ 200 degrees C (3900 liter), top jacket 7 bar @ 200 degrees C (11 liter), straight side jackets 7 bar @ 200 degrees C (3 x 65 liter), bottom cone jacket 7 bar @ 200 degrees C (9 liter), built to TUV, (3) 316L stainless steel jackets on straights side, coned bottom with 316L stainless steel jacket, 750mm diameter x 4850mm long 316Ti stainless steel (1.4571) rotor, rotor driven by a 45/54kw, 3/50/60/380-420/440-480 volt, 1475/1765 rpm motor via a reduction gearbox, mechanical seal, approx 850mm internal diameter, clamped flat top, bottom outlet with a pneumatic operated ball valve, evaporator mounted on carbon steel lugs and in a carbon steel structure, system includes: (1) 8.52 square meter 316L stainless steel (1.4404/1.4435) tube, head and shell vertical condenser, manufactured by Luwa SMS, fabrik #4826102, pressure tube side vacuum @ 55 degrees C (100 liter), shell 6 bar @ 90 degrees C (224 liter), (16) 44.5mm diameter x 2 x 4m long 316L stainless steel tubes, single pass, 324mm diameter 316L stainless steel shell, 4751mm overall length, 316L stainless steel tubesheets, (2) 316L stainless steel dished heads, mounted on lugs, (1) vacuum pump, (1) liquid separator
More Details ⟶
Stock Number: #87894
Evaporation Rate: 430 lb/h
Total Heat Transfer Surface Area: 86.4 ft²
Diameter: 24 in
Height: 180 in
Vacuum: Yes
Additional Information: (3) evaporator sections Separator section 48" dia. Int rated full vac, jkt rated 150 psi @ 393 deg F. Cone btm not jkt. 4-blade rotor. Belt driven by 15 HP, 3/60/220/440 volt, 1140 rpm motor, UL label. Rotor 380 rpm.
More Details ⟶
Stock Number: #221098
Diameter: 13.9 in
Height: 12.4 in
Additional Information: 2.25" shaft, seal housing for a wiped film evaporator. Mechanical seal with cooling lines. 2.25" shaft with key way.
More Details ⟶
Stock Number: #202612
Evaporation Rate: 535 lb/h
Total Heat Transfer Surface Area: 10 m²
Diameter: 800 mm
Height: 204.7 in
Pressure: 4.5 bar
Additional Information: thin film evaporator Equipped with 6 blade fixed rotor Packing gland on shaft. Entrainment separator 500 mm Diameter no pulley and Motor.
More Details ⟶
Stock Number: #202611
Evaporation Rate: 535 lb/h
Total Heat Transfer Surface Area: 10 m²
Diameter: 800 mm
Height: 236.2 in
Pressure: 4.5 bar
Additional Information: thin film evaporator Equipped with 6 blade fixed rotor no Motor. Entrainment separator 500 mm Diameter Packing gland on shaft, with conical bottom
More Details ⟶
Stock Number: #226240
Evaporation Rate: 270 lb/h
Total Heat Transfer Surface Area: 5 m²
Orientation: Vertical
Diameter: 23.6 in
Height: 196.9 in
Pressure: 1 bar
Vacuum: Yes
Additional Information: jacketed wiped film evapaorator jacket 2.76 bar @ 250 deg C, 4- sections of carbon steel limpet coils on body and bottom cone,Rotor with 4-fixed blades (unused Hastelloy C276 spare rotor available) rotor belt driven by 18.5 kw, 3/50/415 volt, 975 rpm Ex motor chamber 600mm diameter x 5m staright side
More Details ⟶
Stock Number: #217821
Evaporation Rate: 25 lb/h
Total Heat Transfer Surface Area: 0.5 m²
Orientation: Vertical
Diameter: 180 mm
Height: 1,400 mm
Pressure: 3 bar
Temperature: 350 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Additional Information: jacketed wiped thin film evaporator with column and condenser pressure internal -1/3 bar @ 250/350 deg C (38ltr) jacket 29.6/26.9 bar @ 250/350 deg C (6ltr) s/steel jacket on straight side only, rotor belt driven by 1.5 kw 3/50/500 volt 710rpm Exd 3nG5 motor, Crane 109 mechanical seal, evaporator with (1) 300mm diameter x 1.8m high 316L s/steel jacketed packed column, manufactured by Dynamite Nobel, fabrik #521, pressure internal: 13 bar + vak @ 200 deg C (140ltr), jacket: 8 bar @ 200 deg C (30ltr), internal coil 8 bar @ 200 deg C (2.5ltr), bolt flat top, weld dsihed bottom, 300mm diameter x 1020mm high packing section, Sulzer packing, (1) 1.2 sqm 316L s/steel (1.4571) tube, shell and head vertical jacketed heat exchanger, pressure tube side: 6 bar @ 200 deg C (40ltr), shell side: 3 bar + vak @ 200 deg C (50ltr), jacket: 8 bar @ 200 deg C 925ltr), (34) 25mm diameter x 2mm x 2.5m long 316L s/steel tubes, shell 250mm diameter x 2140mm total length, (1) dished head, (1) flat bonnet head, all parts are TUV certified
More Details ⟶
Stock Number: #217500
Evaporation Rate: 105 lb/h
Total Heat Transfer Surface Area: 2 m²
Diameter: 340 mm
Height: 2,200 mm
Pressure: 8 bar
Temperature: 0 °F
Additional Information: Luwa wipe film evaporator jacket 4 bar, c/steel jacket 2 x 340mm diameter x 1.1m long clamped sections
More Details ⟶
Stock Number: #102462
Evaporation Rate: 25 lb/h
Total Heat Transfer Surface Area: 5.4 ft²
Diameter: 6 in
Height: 72 in
Pressure: 100 psi
Temperature: 662 °F
Vacuum: Yes
Additional Information: wiped film evaporator/filmtruder body only. jkt rated 227 psi @ 392 deg F.
More Details ⟶
Stock Number: #215306
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215307
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215303
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 323 mm
Height: 8,450 mm
Pressure: 6 bar
Temperature: 100 °C
Additional Information: jacketed horizontal wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts 323.9mm ID x 8450mm long x 7mm thick carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215304
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 323 mm
Height: 8,450 mm
Pressure: 6 bar
Temperature: 100 °C
Additional Information: jacketed horizontal wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts 323.9mm ID x 8450mm long x 7mm thick carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 9 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215305
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 323 mm
Height: 8,450 mm
Pressure: 6 bar
Temperature: 100 °C
Additional Information: jacketed horizontal wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts 323.9mm ID x 8450mm long x 7mm thick carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 9 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm insulated
More Details ⟶
Stock Number: #215308
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 9 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215309
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 9 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm insulated
More Details ⟶
Stock Number: #215310
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell, bolt flat ends, carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm ,insulated
More Details ⟶
Stock Number: #215311
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215312
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser jacket 6 bar @ 100 degrees C (130 liter), 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by 17.5 kw, 3/50/415 volt, 1420 rpm motor via gearbox, shaft speed 55 rpm
More Details ⟶
Stock Number: #215313
Evaporation Rate: 450 lb/h
Total Heat Transfer Surface Area: 8.4 m²
Orientation: Horizontal
Diameter: 12.7 in
Height: 332.7 in
Pressure: 6 bar
Temperature: 100 °C
Additional Information: wiped film evaporator/crystalliser 316Ti (1.4571) stainless steel wetted parts, 323.9mm ID x 8450mm long x 7mm thick shell carbon steel jacket 368mm diameter x 8410mm long x 4mm thick with continuous internal flow spiral 200mm pitch, jacket with expansion bellows, 316Ti (1.4571) stainless steel 88.9mm OD internal scraper rotor, rotor shaft is in 2 pieces which join togeter via a key way, each shaft is fitted with welded lugs to carry scrapers attached to stainless steel springs, the scrappers are made from 25mm x 7mm 'Hartgewebe F24' 546mm long and are arranged with 4 scrapers at 90 degrees and 8 on each shaft, giving a total of 32 per shaft, packed gland on shaft, rotor with teflon bushes, shaft driven by a 2-speed motor, 5.5 kw, 3/50/380/400/415 volt, 950 rpm or 6.1 kw, 3/60/460/440, 1150 rpm via Fenner gearbox
More Details ⟶

Browse used, surplus and secondhand evaporators from IPP – in stock and optimized for chemical, pharma and food processing

Save time and money with IPP’s ready-to-ship evaporators for distillation, purification and thermal separation

Used evaporators are thermal separation systems that concentrate solutions, recover solvents, or reduce waste volume by vaporizing liquid components. These systems are essential across industries where product purity, yield, and cost-efficiency matter. With more than 47 years of industry expertise, IPP offers used, secondhand and surplus evaporators from 20 complete plant sites and a massive inventory of over 15,000 systems ready to ship.

Evaporators are available in multiple configurations—falling film, rising film, forced circulation, wiped film and multiple-effect systems—each tailored for specific viscosity, temperature sensitivity and throughput needs.

Primary uses across industries

  • In pharmaceuticals, evaporators concentrate APIs and remove solvents during intermediate processing
  • In chemical manufacturing, they purify products and reclaim valuable solvents from process streams
  • In food and beverage, they concentrate juices, dairy products, extracts and syrups
  • In wastewater treatment, they reduce volume and recover reusable components

Types of materials processed

  • Heat-sensitive or solvent-based mixtures
  • Aqueous solutions, organic solvents and slurries
  • Viscous liquids and high-solid content mixtures

Common materials of construction

Evaporators are built for long service life, cleanability and chemical resistance:

  • Stainless steel for sanitary and corrosion-resistant applications
  • Hastelloy and other alloys for aggressive chemicals
  • Glass-lined steel for ultra-pure or reactive materials

Key features of industrial evaporators

  • Available as single-effect or multi-effect systems for energy efficiency
  • Options for vacuum operation to protect heat-sensitive materials
  • Integration with distillation, crystallization or solvent recovery units
  • Configurable heating sources: steam, hot oil, or electric
  • Designed for clean-in-place (CIP) and automated control systems

Learn more about evaporator types and applications in process industries from Chemical Engineering.

Find your evaporator at IPP

Search the IPP inventory or contact IPP’s equipment experts to locate the ideal used, secondhand or surplus evaporator for your facility. Whether for concentration, recovery or purification, IPP helps you save time and money with precision systems ready to ship.

Evaporator FAQ

Have questions about Evaporators or our services? Learn more about our products and why customers choose IPP.

What’s the difference between falling film and forced circulation evaporators?
Falling film evaporators are ideal for heat-sensitive materials and lower viscosities, while forced circulation systems handle higher solids and fouling-prone feeds.
Can used evaporators be modified for new applications?
Yes – many units can be reconfigured with new instrumentation, controls or materials of construction to meet changing process needs.
Are multi-effect evaporators more energy efficient?
Absolutely – they reuse vapor from one stage to heat the next, reducing overall steam consumption and operational costs.
What are the benefits of buying used or secondhand process equipment from IPP?
IPP provides faster lead times, cost savings and global support from a team with 47+ years of process plant experience.
