• built to reduce the total NOX to 200mg/m3 of total gas flow as NO2 at fan discharge
• inlet gas flow 138.1 m3/hr
• inlet temperature (10 - 25 degrees C) say design normal = 20 degrees C
• liquor acidification composition 36% CO2 64% N2
• Azide destruction composition 18% NO2 and 82% N2
• Nitrate destruction composition 36% NO2 and 64% N2
• an additional 180m3/hr gas flow into stage 2 tower during purging
• an additional 66m3/hr minimum of oxidation air is added at stage 1 tower inlet
• design code BS4994: 1987 CAT 1
• 10780 liter capacity,
• (2) 1m diameter x 3477m total height Polypropylene lined packed columns, manufactured by Hat International Ltd, design pressure -0.1 barg @ 50 degrees C, bolt flat top, internal spray nozzles, packing is 2 x 1.65m3 of Lanpac 3.5", 2.1m packing height
• (1) Polypropylene lined rectangular holding tank, approx 3.8m long x 1.2m wide x 1.2m high, flat top and bottom,
• (1) 1000 liter Epoxy vinyl Ester resin vertical caustic dosing tank, bolt dished top, weld flat bottom,
• (1) 220/264liter capacity stainless steel dosing pump, manufactured by ProMinent Fluid Control UK Ltd, serial #2007007687, 7 bar pressure, Ex II 2GD IIC T4 x, driven by approx 0.75kW motor,

Vapors handled: NH3, N2, toluene vapor, 100 #/hr HCL, 180 #/hr SOC12 vapor

Downflow dust collector 500 to 3,150 CFM air flow With 4 filter cartriges Housing has a hopper bottom with a manual valve designed to discharge into a pail 3600 rpm blower 3/60/230/460 motor Includes Torit digital controls

Column is 4 sections bolted together. (bottom section is IPP # 246702) Price includes bottom section 246702 Packing is Norton 316L SS 1" pall Ring "Hy-Pak", support assemblies are Norton #818 and Liquid distributer is Norton # 845.

with blower and controls With Blower mounted on the side of the filter housing rated. @ -40 to +30°C, single effect, filter resistance 8 mbar with cone bottom for discharge EEX rated Operating Voltage 230/400 Control panel mounted on side. Mounted on 4 legs.
CE-certified.

Water Softner

multi-effect WFI water distillation unit. All sanitary construction Unit has 5 distillation columns, all national board rated, 145 psi @ 14 to 362 degrees f in the shell; 145 psi @ 14 to 362 degrees f in the tubes. circulation pumps

• Vapors handled: NH3, N2, toluene vapor, 100 #/hr HCL, 180 #/hr SOC12 vapor

reverse jet filters 600 liter capacity chamber weld dished top unit has 10 x filter elements max operating pressure 6.2 bar @ 60 degrees C, min operating temperature -30 degrees C, filter with carbon steel fan design pressure 6.9 bar filter with carbon steel fan, manufactured by Turbovent, type VR25L-1343000, serial #22442, driven by a 2-speed motor, 7.5 kw, 3/50/400-690 volt, 2915 rpm or 9 kw, 3/60/440/480 volt, 3510 rpm, openings side 1-450mm inspection port, 1-75mm, bottom 1-500mm discharge, unit mounted on carbon steel skid,

Rated -150/50 MBar. Filter area is 8 m2 with cone bottom. Bolted top manifold that is 16" straight side. with 1.5" diameter manifold feed line, (2) pulse jet feed lines. With CS fan. Rotary Airlock valve on bottom.

• This is a flameless oxidizer, there is no burner and it only accepts a gas flow.

exhaust air scrubber, pressure rated -1/0,5bar @ -10/160 degrees C, mounted on a carbon steel frame with a 150 mm diameter stainless steel body scrubber column with carbon steel rushig rings pressure rated 6bar@ 50 degrees C, with a pump, manufactured by Dickow, type WPVh2561, serial number 03175440 motor type FFD80K4FDS/6612 motor and pump are CE stamped.

Booster Pump skid designed to increase water flow , temperature, and pressure for RO system, and CID system in the following steps of the process. With one approx. 10 sq ft, ITT Industrial plate heat exchanger model P7A, with 316 SS SS plates rated for 150 psi at 302 degrees F on both the process or service side One, 5 HP, 316 SS centrifugal pump rated for 60 psi one 5 micron filter in a 316 SS electropolished housing manufactured by Stainless Fluid systems 0.8" OD x 41" high, with 1.5" inlets and outlets The filter vessel is rated for 150 psi at 300 degrees F. UV lamp, rated for 254 NM, in a 316 SS polished housing With digital flow controls, and a US filter power control panel.

• polypropylene scrubber system,
• gas flow 500m3/hr,
• IF gas leakage 1500m3/hr,
• flow rate 2-20m3/hr,
• max pressure drop across packing 25mbar, across scrubber 37mbar,
• volume 3100 liter,

(1) 630mm diameter x 7700mm total height Polypropylene column, design pressure internal -70/150 mbar @ 36/170 degrees C, 2-packed sections, 1=2.8m high (0.8 m3), 1=3.2m high (0.86 m3), Hedgehog IGEL 43 packing type, distribution plates, spray nozzle, droplet separator,

(1) Polypropylene sump tank, 1330mm long x 750mm wide x 1m high, flat top and bottom,

(1) Polypropylene venturi scrubber, manufactured by GEA Wiegand,

(2) 20m3/hr @ 50m head PFA lined centrifugal pump, manufactured by Richter Chemie-Technik, type PCK/F 40-200, serial #927054/2/1 & 927054/2/2, 2900 rpm, 192mm diameter impellor, mechanical seal, driven by 11kW, 3/50/415 volt 2940 rpm EEx de IIB T4 motor, mounted on a baseplate,

(1) 1.74 square meter 316 stainless steel plate heat exchanger, manufactured by APV Baker Ltd, type SR2613, serial #SR2613 10/2, design pressure both sides 6/8 barg @ 80 degrees C, (12) 316 stainless steel plates, carbon steel pressure plates and frame, design code BS5500 CAT 2 1991,

• design pressure -50/450 mbar @ 200 degrees C,
• total capacity 2582 liter,

(1) 600mm diameter x 3m high PTFE lined spray column, design pressure -0.005/0.045 barg @ 200 degrees C, total 840 liter volume, 6-internal recirculation spray nozzle,

(1) venturi leg,

(1) 1595 liter PTFE lined holding tank, 1.2m diameter x 1060mm straight side, bolt dished top and bottom, mounted on legs,

design code BS5500 CAT 2,

1.4m diameter Polypropylene scrubber column system, manufactured by Malaguti Impianti, 4500 m3/hr flow, column capacity 1500 liter, coned top, flat bottom, internal spray pipes, pipework,

vertical cyclone, weld slight coned top, weld coned bottom, openings top: 1-900mm, straight side: 1-800mm, bottom: 1-250mm, mounted on 4-lugs

vertical cyclone, weld slight coned top, weld coned bottom openings top: 1-900mm, straight side: 1-800mm, bottom: 1-250mm, mounted on 4-lugs

vertical dust collector mounted on legs with a 30" cone bottom Contains socks approximately 6" diameter x 70" long Side access door 40" long x 21" wide. with a 15" diameter Fike rupture disk Pulsater top is 12" long Bottom outlet on cone is 6.5" and has a manual slide gate valve Cone bottom has a 4", 3", and a 2.5" flanged nozzles Top has a 3" nozzle. Legs elevate collector 36" off grade.

with (6) 4" diameter x 92" long filtration tubes Model SS1832B-12400, Serial number 4878325 mechanical seal on shaft

Discharge Cone and Parts Material: 321 SS Dirty Air Chamber Dimensions: 36” diameter x 45” long Vertical Removable top cover, 321 SS cyclone discharge cone Discharge Cone: 48” diameter x 12” with a 5” inlet, and a 36” tapered cone to a 5” outlet on bottom Top cover is removable for access to filters, and is counter weighted and secured by Stay Con clamps Bottom cyclone has two 10” wide x 24” long access doors,(orientated 180 degrees). Two 12” diameter x 26” long cartridge filters Each filter has 175 pleats, 2" wide x 25" long Each cartridge has 121 sq. ft. of surface area Four 6” x 9” lugs for mounting, attached at top of bottom cone weld seam One 5” clean air discharge One 5” clean air discharge, one 24” inspection door for man way or pressure relief disk.(not available)

vertical cyclone separator bolted coned bottom section weld slight coned top

vertical cyclone weld slight coned top, weld coned bottom openings top: 1-900mm, straight side: 1-800mm, bottom: 1-250mm, mounted on 4-lugs

Six filter cartridges Top mounted fan, 15 HP, 208/230/460 v, 3500 rpm. Mounted on legs

4000 Liter/Hr.(17 GPM) clean in place skid Skid contains the following major pieces, one condenser, two tanks, two pumps, and a on board control panel. Two 400 Liter tanks with open tops and welded slight cone bottoms.(Solution supply & return tanks) two sanitary centrifugal pumps by Inoxpa, and controls with a Siemens HMI. Heating capacity 4000 Liters/hr., Heat transfer area 0.9 m2, Temp rise 50 -60 degrees C, steam consumption per hour 80 kg/hr
