Conveyors, Bins, Tanks, and more

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

Rated 2000 lbs./Hr. at 40 lbs./Cu.Ft. Two-(2) 5' 9 &3/8 cooling sections. Rotation: Clockwise.

• 6300 liter working volume
• CE6300 series,
• design pressure -1/3.5 bar @ -25/170 degrees C (7575 liter),
• glass type 3009U,
• design code: AD-M 2000, CAT IV, 97/23/EC,

fork liftable product tote bin

#4 inside with welds ground and polished
Lifting eyes on top of the tank
3” Tri- Clamp connections
Insulation - 1” cork with mild steel insulation

• Sanitary Insulation Shroud

• 10000 liter working capacity,
• design pressure internal 3.5 bar + full vacuum @ 100 degrees C (10820 liter),
• internally highly polished to 0.5 to 0.8 microns,
• design code: BS5500 1997 CAT 2
• top platform and vertical ladder available if required

• Polished Standards: CODAP 90with (2) stainless steel handles on side wall to moving the tank.

• design pressure 0.17/3.5 bar @ -15/100 degrees C,
• design code: ASME VIII DIV 1 (latest)

(1) 10 m3/hr @ 35m head 316 stainless steel centrifugal pump, manufactured by CP Pumpen Ag, serial #06-00784/51642, type MKP 40-25-160, pressure 16 bar @ -30/200 degrees C, differential pressure 5.5 bar, NPSH 1.2m, driven by 5.5kw 3/50/400 volt 2911 rpm IP65 Eex de IIBT4 ATEX motor, magnetic drive, openings suction 32mm, discharge 25mm, mounted on a baseplate

• design pressure 1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV. 1. 1989 (DEC 90 ADDENDA)

With (2) PTFE lined centrifugal pumps, manufactured by Richter Chemie, type PCK/F 32-160, 2900 rpm, 165mm diameter impellor, mounted on a base plate,

• working capacity 1600 liter
• design pressure internal 3.5 bar + full vacuum @ -25/170 degrees C,
• design code: PD5500-2000-MODULE G-GAS GROUP 1

• 316L stainless steel electro highly polished inside/outside hopper,
• pressure -0.5/0.5 bar @ 100 degrees C,
• pneumatic actuated valve on bottom discharge,
• hopper with a 316L electro polished 98 liter stainless steel PTS 400-C (powder transfer system), serial #PTS-4587, pressure -1/3 bar @ 100 degrees C,
• design code PED group 2, Cat 1, Module A,
• with (2) filters

• Constructed of 316Ti (1.4571) stainless steel.
• With 14 liter internal 316Ti coil: one turn, 900mm wide X 6620mm long.
• Coil designed for 6 bar pressure at 100 deg. C.

• Repaired by Alfonso Serial Number 9138-86 (3) reinforcing rings around straight side of tank

Heads are .375" thick

Derakane 411

Twin screw
Feed conveyor for a porcupine processor
Inlet size is 48" x 30"
Triple chain drive sprocket.(No motor or gearbox)

• Variable head thickness: top head 0.3", bottom head 0.291"

• Built to BS 5500:1994 code.

Vapor body/separators for evaporation system
Vapor head and swirl breaker dimensions: 68" diameter x 148" long with a slight cone
drop leg is 12" diameter x 120" long.
All welded construction

• Lined with 3009 glass.

• Pressure tank, CRN # K.5857.5, OIN # 5.882526
• Head thickness 0.25"
• Overall height 140 "

• Lined with 9115 glass.

• With two top lifting lugs.
