tube pressure rated by -1/10bar @-10/200 degrees C (volume 66 liter), shell pressure rated by -1/10bar @ -10/200 degrees C (volume 180 liter) Length: 188.5 in. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 121. Tube Diameter: 0.55 in. Tube Length: 165.4 in. Tube Thickness: 0.06 in. Nozzle Schedule: shell side: (1) DN100, (2) DN200, (1) DN300; tube side: (1) DN150, (1) DN200. Capacity: 65 gallons. Heat Exchanger Tube Capacity: 17.4 gallons.

side A = 550 ltr, side B = 570ltr

pressure both sides -1/10 bar @ -50/150 degrees C (18 liter/17 liter) fully insulated, CE-0036,

Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.

2-stage (2) 450 Sq Ft condensers bolted together, end to end, with same configuration and material in both stages, Upper stage and lower stage each have a 316LSS shell, CS heads. Shell is 0.135" thick, Heads are 1.12" thick CS. Spiral Material: Stainless Steel 316.

• Cooling water lines: two 8" lines. 2 pass design Tube Type: Straight Tube. Tube Number: 250. Tube Diameter: 1.25 in. Tube Length: 192 in. Tube Thickness: 0.06 in. Nozzle Schedule: - Inlet: 18" vapor inlet - Outlet: 4" vapor outlet.

AL6XN channel heads with R-Stamp(1994) Tube Diameter: 1.25 in. Tube Length: 144 in. Tube Thickness: 0.02 in. Nozzle Schedule: - Nozzle Schedule: - Two 32" tube side nozzles (brine inlet & outlet) - One 18" steam inlet - One 4" condensate outlet - One 3" drain - Two 1" drain/vents.

• Type: Horizontal graphite spiral block heat exchanger
• Weight: 210 KG Product Side -1/3 bar@ -20 to +165 degrees C 17 liters

(2) 300mm high cone sections,

Heads are CS faced with 316 L SS Spiral Material: Stainless Steel 316L.

Process sidde rated 45 PSI @ -30/+122 degrees F. Service side rated 30 PSI @ -30/+122 degrees F.

cubic block heat exchanger process side is 2-pass with (2160) slots, 9.5mm x 3mm, service side is multi-stage with (756) 9.5mm diameter tubes can be used vertical or horizontal.

Rated 300/FV @ -20 to 425 degrees tube side; FV/50 psi @- 20 to 425 degrees F shell side. clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.

40" diameter x 12' horizontal. Tube Number: 376. Tube Diameter: 0.87 in. Tube Thickness: 1.25 in. Nozzle Schedule: Nozzle Schd:(3) 6" .

• Design code: ASME VIII DIV I,PED CAT III gas group 1, Not NB stamped
• CE0040
• CE certified
• Fluids circulated service side =water, process side = Toluene Pack Material: Graphite. Process Temperature: 365 °F. Service Side Passes: 22. Process Side Passes: 9. Service Side Capacity: 25.4 gallons. Process Side Capacity: 11.4 gallons.

Rated 150/FV @ -20 to 400 degrees F tube side 150/FV @ -20 to 400 degrees F Shell Side Unit has (2) bolted flat heads (1) Tanalum, (1) CS with tantalum lining Length: 94.5 in. Tube Number: 84. Tube Diameter: 0.75 in. Tube Length: 72 in. Nozzle Schedule: - Nozzles: Shell side has two 4" nozzles with 1" reducing flanges - Inlet/outlet: Tube side inlet is 4", tube side outlet is 3" with a 1" drain..

Bolted heads with Tantalum lining Top head is 9" long, bottom head is 13" long. Nozzle Schedule: Shell side openings are two 2", tube side in is 3" tube side out is 1"..

working pressure tube side 150 psi (10.3 bar) + full vacuum @ 400 degrees F (204 degrees C), shell side 150 psi (10.3 bar) + full vacuum @ 400 degrees F (204 degrees C) single pass 200mm I.D 304L stainless steel shell with expansion bellows (2) 304L stainless steel heads with Tantalum lining (1) flat channel head Tube Number: 33. Tube Diameter: 0.75 in. Tube Length: 89.8 in. Nozzle Schedule: - Tube side openings: Coned head with 1-100mm, flat channel head with 1-50mm - Shell side openings: 2-80mm.

0.750" diameter x 16 ga wall thickness 2 pass Tube Number: 88. Tube Diameter: 0.75 in. Tube Thickness: 0.06 in. Nozzle Schedule: - Tube side nozzles: two 6" - Shell side nozzles: two 8".

Hastelloy B2 (SB-626) tubes, 16" diameter x 6' 1.5" long tube sheet to tube sheet. Tube Diameter: 0.75 in. Tube Length: 73.5 in. Tube Thickness: 0.06 in. Nozzle Schedule: One 6" nozzle, four 3" nozzles, three 2.5" nozzles..

Carbone polybloc heat exchanger

Tantalum clad heads 18" diameter x 75.25" Overall length. (face to face 48") Length: 75.3 in. Tube Type: Straight Tube. Tube Number: 168. Tube Diameter: 0.7 in. Tube Length: 48 in. Tube Thickness: 0.015 in. Nozzle Schedule: Shell side - two 4", Tube side - one 8" and two 3"..

304L SS with Hastelloy C clad tube sheet Hastelloy lined CS shell Length: 60 in. Tube Type: Straight Tube. Tube Number: 333. Tube Diameter: 0.75 in. Tube Length: 26 in. Tube Thickness: 0.03 in. Nozzle Schedule: One 8" nozzle, One 4" nozzle, three 3" nozzles. .

Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 130. Tube Diameter: 0.75 in. Tube Length: 72 in. Tube Thickness: 0.07 in. Nozzle Schedule: Two 6", two 3".

Length: 61 in. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 212. Tube Diameter: 0.75 in. Tube Length: 47.8 in. Tube Thickness: 0.07 in. Nozzle Schedule: one-8", two 3", two 2" and two 1".
