Used disc bowl centrifuges for sale: precision clarification for continuous liquid processing
Highest-ranked available inventory for this selection.
Used disc bowl centrifuges for sale: precision clarification for continuous liquid processing
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 25 of 103 matching Disc Bowl Centrifuges.
2-chamber bowl clarifier centrifuge. Complete with bowl, parts and tools in separate crate.
Disc bowl automatic desludger Purifier/clarifier design (3 phase) Timer triggered total discharge Paring disc on both light and heavy phases
disc bowl centrifuge. Separator (3-phase) design. Special design for glucose separation Cast iron frame w/brake, oil level sight glass and revolution indicator for bowl speed check Drive by standard flange mount motor. Power transmission to bowl spindle via centrifugal friction clutch and worm gear. All bearings and the gears splash lubricated from a central oil bath. Pressure discharge of the heavy phase via built-in centripetal pump and gravity discharge of the light phase.
solids retaining disc bowl centrifuge Material of bowl is s/steel 2205 Purifier (3-phase) design Paring disc on both light and heavy phase.
Pharma grade GMP sanitary construction
Designed for Biotech cell harvesting
Rated 5 gpm on Pharma broth
with a Broom Motors LTD
Also includes a 1 m2 plate and frame heat exchanger manufactured by Sondex, rated for 10 kp/cm2 at 150 degrees C
rebuilt disc bowl self cleaning solids 1.25 kg/dm3, heavy solid 1.1 kg/dm3, The product flows into the bowl through inlet and is separated in disk stack into a light and a heavy liquid phase with simultaneous removal of the solids which collect in the sediment holding space. The light liquid phase flows towards the center and is discharged foam-free and under pressure by centrifugal pump through outlet. The heavy liquid phase flows to the periphery and is discharged under pressure by centrifugal pump through outlet. The separated gums and solids collect in sediment holding space and are instantaneously ejected through ports at pre-set intervals by lowering the sliding piston. Closing water drains via the bowl valve. The ejection cycles are initiated by a control unit
disk bowl separator system, solids 1.3 kg.dm3, heavy solid 1 kg/dm3
(1) 450 liter 316Ti stainless steel vertical tank, manufactured by Hinke, fabrik #8784, pressure -0.3/+0.49 bar @ -0/+90 degrees C (450 liter), weld flat top and bottom, mounted on legs, (1) 3.5/5/12 m3/hr @ 51/50/47m head 316 stainless steel centrifugal pump, manufactured by Dickow Pumpen, type NMBh 26/210, fabrik #9716261, 2900 rpm, 4.1/3.3/4.1kw, driven by 2.5kw, 3/50/380/660 volt, 2840 rpm motor mounted on a baseplate
The separator is equipped with a self-cleaning disc-type bowl. The product flows into the bowl through inlet and is separated in disk stack into a light and a heavy liquid phase with simultaneous removal of the solids which collect in the sediment holding space. The light liquid phase flows towards the center and is discharged foam-free and under pressure by centripetal pump through outlet. The heavy liquid phase flows to the periphery and is discharged under pressure by centripetal pump through outlet. The separated gums and solids collect in sediment holding space and are instantaneously ejected through ports at pre-set intervals by lowering the sliding piston. Closing water drains via the bowl valve. The ejection cycles are initiated by a control unit
Separator (3-phase) design Cast iron frame w/brake, oil level sight glass and revolution indicator for bowl speed check. Drive by standard flange mount motor. Power transmission to bowl spindle via centrifugal friction clutch and worm gear. All bearings and the gears splash lubricated from central oil bath. Pressure discharge of the heavy phase via built-in centripetal pump and gravity discharge of the light phase.
frame with out bowl. Clarifier (2-phase) design IP55 motor Cast iron frame w/brake, oil level sight glass and revolution indicator for bowl speed check. Drive by standard flange mount motor. Power transmitted via centrifugal friction clutch and worm gear to the bowl spindle. All bearings and the gear splash lubricated from central oil bath. Pressure discharge of the clarified liquid by built-in centrifugal pump.
nozzle disc centrifuge machine #1671-563 1.2 kg/dm3 solids bowl #3230-6645-010 (563) Driven by Loher EX motor via V-belt assembly with hydraulic powerpak driven by 1.5 KW, 3/50/500 volt motor Stand for cone assembly.
Frame SN 1647477, bowl SN 1641173 Has tools, controls and manuals.
329 stainless steel bowl And 316 stainless steel Clarifier centrifuge with intermittent solids discharge
disc nozzle centrifuge Internal nozzles with paring device Used for 10 yrs for yeast production Tachometer 1420-1500 rpm
With internal nozzles and paring device Used for 10 yrs for yeast production. Tachometer 1420-1500 rpm Speed counter 118-125 rpm Driven by 45 KW, 3/50/380 volt, 1470 rpm motor Openings: top 1-2" (50mm), 1-1" (25mm); btm 1-6 1/2" (164mm)
motor enclosed in SS sanitary housing. Rated 10000-12500 litre/hr milk Hood material of construction 1.4541 (321SS). Ken #34016001, ELN #13352210, Reg #170
separator double paring disc 1.1 KW/1.5 KW, 3/50/220/380 volt 1420 rpm motor Tools
When your process demands precise, continuous separation of immiscible liquids or fine solids from liquids, disc bowl centrifuges offer superior performance for critical applications. With more than 47 years of experience, IPP offers immediate access to high-quality used disc bowl centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used disc bowl centrifuges from IPP provides companies with faster project timelines, significant cost savings, and proven process reliability.
Disc bowl centrifuges, also known as disc stack centrifuges, operate by spinning a series of conical discs at high speeds to enhance the separation of solids and liquids or two immiscible liquids with different densities. They are essential for processes requiring continuous clarification, purification, or concentration.
Learn more about disc centrifuge technology at Chemical Processing.
Search the IPP inventory or contact IPP’s equipment experts to find the perfect disc bowl centrifuge for your separation needs. With ready-to-ship inventory, IPP helps companies shorten commissioning timelines, reduce equipment costs, and optimize product quality.
