Showing 17 of 17 matching Scrubbers.
Vapors handled: NH3, N2, toluene vapor, 100 #/hr HCL, 180 #/hr SOC12 vapor
Column is 4 sections bolted together. (bottom section is IPP # 246702) Price includes bottom section 246702 Packing is Norton 316L SS 1" pall Ring "Hy-Pak", support assemblies are Norton #818 and Liquid distributer is Norton # 845.
exhaust air scrubber, pressure rated -1/0,5bar @ -10/160 degrees C, mounted on a carbon steel frame with a 150 mm diameter stainless steel body scrubber column with carbon steel rushig rings pressure rated 6bar@ 50 degrees C, with a pump, manufactured by Dickow, type WPVh2561, serial number 03175440 motor type FFD80K4FDS/6612 motor and pump are CE stamped.
Typical operating conditions: Recirculation to VF573 is 15-21 GPM. Recirculation to VF572 is 0.5-0.7 GPM 10% Naoh is make up to VF574 (not supplied) Discharge stream dependent on pH and temperature.
Fiberglass (Derakane 470), acid mist scrubbing system. Designed to treat acid laden fumes prior to atmospheric discharge. Manufactured by Celicote, model SPT-12-60. Rated for -2” WC to +6” WC up to 150 degrees F. Major components are tower VF573, VF574, tower VF 572, and pumps, IPP stock numbers 233893 and 233896 Tower VF573 is Fiberglass Derakane 470, and bolts by a flange to vessel VF574 Its specifications are 24” diameter x 186” overall length. Flange for bolting to tank is 24”. Side mounted nozzles are one 9”, two 8”,two 4.25”, and two 4” Outlet flange is 6”. This column is packed with saddles. Recirculation tank (VF574) is fiberglass (Derakane 470) , and has a capacity of 1200 gallons It is 64” diameter x 105” long with dished heads , and has the following nozzles: One 24” nozzle for VF573, one 19” top nozzle, two 5” nozzles, one 3” nozzle and four 1.5” nozzles Secondary gas stream flow is handled by VF572, Derakane 470, packed tower containing plastic tellerettes This tower is 15” diameter x 151” long, and has one 6” nozzle, two 4” nozzles, three 1.5” nozzles, and one 1” nozzle. Recirculation is handled by a Teflon lined centrifugal pumps, (IPP stock numbers 233896 & 233893) one is operational and the other an in line spare.
Their specs are as follows: 160 GPM at 80 Ft./Hd., Teflon lined wetted end, horizontal centrifugal pump. Manufactured by Durco. Mark II Serial # 0605-2071. 3 x 2 x 10 with a mechanical seal on shaft. Base mounted and direct driven. Powered by a Reliance Duty Master 10 HP AC motor. rated for 1755 rpm, 230/460 volt, 23.8/11.9 amp, 3 phase 60 Hz. TEFC Enclosure. Frame L 215 T. 50" long x 22" wide x 22" high. Typical operating conditions are as follows: Recirculation to VF573 is 15-21 GPM. Recirculation to VF572 is 0.5-0.7 GPM. 10% Naoh is make up to VF574.(not supplied) Discharge stream dependent on pH an temperature. Blowers not available but can be supplied separately.
(1) 630mm diameter x 7700mm total height Polypropylene column, design pressure internal -70/150 mbar @ 36/170 degrees C, 2-packed sections, 1=2.8m high (0.8 m3), 1=3.2m high (0.86 m3), Hedgehog IGEL 43 packing type, distribution plates, spray nozzle, droplet separator,
(1) Polypropylene sump tank, 1330mm long x 750mm wide x 1m high, flat top and bottom,
(1) Polypropylene venturi scrubber, manufactured by GEA Wiegand,
(2) 20m3/hr @ 50m head PFA lined centrifugal pump, manufactured by Richter Chemie-Technik, type PCK/F 40-200, serial #927054/2/1 & 927054/2/2, 2900 rpm, 192mm diameter impellor, mechanical seal, driven by 11kW, 3/50/415 volt 2940 rpm EEx de IIB T4 motor, mounted on a baseplate,
(1) 1.74 square meter 316 stainless steel plate heat exchanger, manufactured by APV Baker Ltd, type SR2613, serial #SR2613 10/2, design pressure both sides 6/8 barg @ 80 degrees C, (12) 316 stainless steel plates, carbon steel pressure plates and frame, design code BS5500 CAT 2 1991,
(1) 600mm diameter x 3m high PTFE lined spray column, design pressure -0.005/0.045 barg @ 200 degrees C, total 840 liter volume, 6-internal recirculation spray nozzle,
(1) venturi leg,
(1) 1595 liter PTFE lined holding tank, 1.2m diameter x 1060mm straight side, bolt dished top and bottom, mounted on legs,
design code BS5500 CAT 2,
1.4m diameter Polypropylene scrubber column system, manufactured by Malaguti Impianti, 4500 m3/hr flow, column capacity 1500 liter, coned top, flat bottom, internal spray pipes, pipework,
Vapors handled: NH3, N2, toluene vapor, 100 #/hr HCL, and 180 #/hr SOC12 vapor The system uses various recirculation streams depending on the vapors and removes 95-85% of the vapors depending on the conditions. The system utilizes CS construction for the tank and column, lined with “Flouroshield” Teflon, and also included are a recirculation pump and heat exchanger. The system design rating is FV/5 psig at 5-200 degrees F. The pump is a Gould’s size 1 x 1.5 x 8, model 3298, mag drive, and a Tefzel liner, driven by a 7.5 hp. Ex. Proof motor The heat exchanger is an APV Model SRS MS-12 with Hastelloy C-276 wetted parts and a surface area of 101.8 Sq.Ft. The column packing is Hi flow 5/8” rings manufactured from PFA Teflon, With an Otto York mist eliminator Complete package system base mounted on a CS base 9’ long x 7’ wide. Top of the column is 106” high.
GRP jet scrubber system
(1) GRP horizontal receiver tank (HCI scrubber), design pressure -1/3 barg @ 20/180 degrees C, material of construction 470-300 HDT Vinyl ester resin, dished ends, 4-GRP jets mounted on the top openings,
(1) approx 250mm diameter Hastelloy C22 column (quench spool), manufactured by Able Engineering, serial #HY15579, design pressure -1/3 barg @ 210 degrees C,
(1) centrifugal pump
glass scrubber system consisting of (1) Schott QVF packed column, 165mm diameter x 2m high, (1) Schott QVF glass packed column, 225mm diameter x 2m high,
Using caustic to scrub acid. Fan was removed, we can replace it. Packed section 4.5 feet, with structured mesh packing. Multiple spray bars at top of tower, 3" feed/spray line, 4" return line. 14" gas inlet. Scrubber fan speed 3600 rpm.
(1) 600mm diameter x 3m high PTFE lined spray column, design pressure -0.005/0.045 barg @ 200 degrees C, total 840 liter volume, 6-internal recirculation spray nozzle,
(1) venturi leg,
(1) 1595 liter PTFE lined holding tank, 1.2m diameter x 1060mm straight side, bolt dished top and bottom, mounted on legs,
design code BS5500 CAT 2,
82 acfm- 28 acfm 4”- 48” Packaged scrubber system Designed to handle an 82 acfm gas stream of NH3, N2 and toluene vapor at 15” wc It will also handle 28 acfm of 100 #/hrHCL and 180 #/hr of SOC12 vapor The system uses various recirculation streams depending on the vapors and removes 95-85% of the vapors depending on the conditions The system utilizes CS construction for the tank and column, lined with “Flouroshield” Teflon, and also included are a recirculation pump and heat exchanger mag drive and a Tefzel liner Ex. Proof motor The column packing is Hi flow 5/8” rings manufactured from PFA Teflon, With an Otto York mist eliminator. Complete package system base mounted on a CS base 8’ long x 6’ wide Top of the column is 106” high
Gas stream: NH3, N2, toluene vapor (82 acfm at 15" wc), HCL (28 acfm at 100#/hr), SOC12 vapor (180#/hr) Tank and column construction: CS construction, lined with "Flouroshield" Teflon
Used scrubbers are critical to air pollution control in industrial settings, removing particulates, hazardous gases, and vapors from process streams. Whether you need a packed bed scrubber for chemical neutralization or a venturi scrubber for particulate removal, IPP offers ready-to-ship gas scrubbing systems from 20 plant sites worldwide. With over 47 years in business, IPP supplies more than 15,000 pieces of process equipment to customers in pharma, chemical, food, and energy industries.
IPP’s inventory includes wet scrubbers, dry scrubbers, spray towers, packed towers, and multi-stage systems from brands such as Ducon, Monsanto Enviro-Chem, Croll-Reynolds, and CECO.
Learn more about scrubber technologies and performance factors via the U.S. EPA.
Browse IPP inventory or contact IPP to speak with a gas scrubbing expert. Whether you need a simple packed tower or a complex multi-gas system, IPP can help you save time and money with surplus scrubbers in stock.
