Used inverting filter centrifuges for sale: automated solid-liquid separation systems
Highest-ranked available inventory for this selection.
Used inverting filter centrifuges for sale: automated solid-liquid separation systems
Set a numeric threshold to narrow the matching listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 15 of 15 matching Inverting Filter Centrifuges.
All wetted parts are 316SS electro polished to 180 grit Designed for 10 to 30 gpm feed rate The unit has EPDM seals and a polypropylene filter cloth The axial drive is 1 HP 3/60/460 volt 1800 rpm.
cake capacity 55 liter centrifugal force: 1250 xg with translation powe rpack, with filtrate discharge tank 875 mm diameter x 700 mm straight side with a 500 mm top opening,, mounted on stand, with control cabinet and stairs
Heinkel Inverting Filter Centrifuge Seals made with silicon- teflon. DIN 24400, to 40 mbar. XP T4 Cake volume: 52.2 liter Operating temperatures: From +20 to +80 degrees C. IP55 motor with frequency converter. Control panel
inverting filter centrifuge Rated 1150 RPM Solid Haynes Hastelloy C22 for all process parts 316SS for balance of exterior parts Clean in place nozzles for solids and filtrate housings Polished to 180 grit and electropolished solids and filtrate housings Electric Rotational Drive, Hydraulic Axial System, Maximum Speed 1600 rpm and G force of 1150 G's Bowl Diameter 800 mm or 32 ", Maximum Fill Weight 149 kg Maximum Fill Quantity 119 liters Nitrogen Purge Panel Designed for Axial Hydraulic Skid Built in 1990 for pharmaceutical industry
1.4571SS with halar lining Cake capacity: 52.2 liter Centrifugal force: 1200 xg With filtrate discharge tank 875 mm diameter x 700 mm straight side with a 500 mm top opening With hydraulic translation powerpak driven by 3.0 kW 3/50/380V 1500 RPM motor. Control panel. Vibration dampers.
Heinkel Inverting Filter Centrifuge, hinged front cover 50mm feed, 880mm x 580mm discharge, 125mm filtrate 500 liters of suspension/hour with dry matter of 75%
316L stainless steel hinged front chamber carbon steel housing hydrostatic driven
explosion class E Exde II CT4, non-wetted parts 316L stainless steel (1.4571) Teflon seals inverting mechanism driven by 5.5 kw, 3/50/500 volt, 1500 rpm E Exd II CT4 motor, feed pipe with 1.5kw, 3/50/500 volt, 1500 rpm E Exd II CT4 motor, hinged front door, CE and TUV certified
Filter Centrifuge.
inverting centrifuge machine # 1003/11 940 kps Aggregate: L x H x W (length x high x width) 1200mm x 1500mm x 530 mm. with hydraulic pump and controls.
new bearings, seals, belts, rebuilt hydraulic unit, and run in by the OEM 1600 RPM Maximum Solid Haynes Hastelloy C 22 for all process parts, 316SS for balance of exterior parts Clean in place nozzles for solids and filtrate housings Polished to 180 grit and electro polished solids and filtrate housings. Electric Rotational Drive hydraulic Axial System Bowl Diameter 800 mm or 32 ", Maximum Fill Weight 149 kg Maximum Fill Quantity 119 liters Explosion proof for Class I Division I C + D Motor. One HF 800 unit is equivalent to approximately one to two 48 basket units in capacity estimated only Usually 100-200 kgs per hour wet product estimated only.
Inverting filter centrifuge Cake capacity: 52.2 liter Centrifugal force: 1200 xg With filtrate discharge tank 875 mm diameter x 700 mm straight side with a 500 mm top opening with translation powerpak. Control panel. Floor space required: 290 mmL x 1750 MMW x 1410 mm H
When your process requires gentle, efficient solid-liquid separation with minimal product loss, inverting filter centrifuges provide superior performance across critical industries. With more than 47 years of process equipment expertise, IPP offers immediate access to used inverting filter centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used inverting filter centrifuges from IPP helps companies save capital, accelerate project schedules, and achieve excellent product recovery.
Inverting filter centrifuges feature a unique design where the filter cloth is mechanically inverted during discharge, gently removing solids without damaging fragile crystals or products. These machines are ideal for high-purity applications requiring low residual moisture, minimal contamination, and easy cleaning between batches.
Inverting filter centrifuges are built to meet sanitary, chemical, and high-purity standards:
Learn more about advanced centrifuge separation techniques from Chemical Processing.
Search the IPP inventory or contact IPP’s equipment experts to secure an inverting filter centrifuge for your high-purity or sensitive separation needs. With ready-to-ship inventory, IPP helps companies meet demanding quality standards, shorten lead times, and control equipment costs.
Have questions about Inverting Filter Centrifuges or our services? Learn more about our products and why customers choose IPP.
