standard 6' diameter bucket with 18" diameter manway and 8" diameter outlet with 9 to 45 rpm on bucket with Hastelloy vacuum arm with stuffing box. With bull and pinion Reconditioned gear box, driven by 3HP XP class 1, div 2 , 3 phase, 60HZ, 230, 460 Volt motor with electric 10 ft-lbs. brake.

internal pressure -1/1 bar @ -10/200 deg C (4310ltr), jacket 6 bar @ -10/200 deg C (480ltr) 1m high top and bottom cones gear driven by a vari-speed drive 3/50/300/660 volt Hastelloy vacuum arm, mechanical seal, rotary union joint top cone with 1-450mm manway, bottom cone with 1-250mm discharge with valve (1) s/steel plate heat exchanger, 70 kw, pressure 16 bar @ 150 deg C (1) 8-28 m3/hr c/steel centrifugal pump, 14.5-9.5m hd,

• Tumble vacuum dryer system. Designed for 50 lb./cu ft product weight Driven by 10 HP 3/60/460V, 1750 RPM motor through Reeves variable speed drive(2)18" charge ports, 1-18" discharge port with pneumatic operated valve Skid mounted vacuum system consists of a Graham type 2PV 52120/12/43/1 two stage water seal vacuum pump driven by 10 HP 3/60/460V, 1760 RPM motor. 102 Sq. ft., Horizontal stainless steel tubes, tube sheets, heads, steel shell heat exchanger, 150 gallon jacketed stainless steel condensate receiver with all gas contact surfaces of stainless steel skid mounted electric source heating system ( 250 degrees F at 30 psi) contains an 80KW electric immersion heater, single suction centrifugal pump, expansion tank, and a cooler.(PK heat exchanger, liquid to liquid). W202094 stored at DW12 (S). JB

dryer (bucket only) Glass # 5015 Internal pr

Gear driven by a cone gear drive approx 3 HP.

25 PSI with FV internal. 6 Ft diameter body. Bull and pinion gear 230/460 volt gear head motor with electric brake 5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft, Hastelloy 276-C vacuum arm. 18" carge prort with cover Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.

glass 3113 Dryer body 2100 mm diameter x 1200 mm conical sections Jacket volume: 440 liter with gear reducer With 450 mm manway Jacket's heat transfer area: 13.4 square meters

45 PSI with FV internal. 6 Ft diameter body Bull and pinion gear 230/460 volt gear head motor with electric brake 5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft, Hastelloy 276-C vacuum arm. 18" carge prort with cover Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.

25 PSI with FV internal Bull and pinion gear 230/460 volt gear head motor with electric brake 5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft, Hastelloy 276-C vacuum arm. 18" carge prort with cover Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.

• Vacuum tumble dryer system. Designed for 50 Lbs/ cubic foot density.
• Dryer driven by 10 HP 3/60/460V XP motor with Reeves variable speed drive.
• With (2) 18" diameter charge ports, 1-18" diameter discharge port with pneumatic operated valve.
• Equipped with skid mounted vacuum system including a Graham two stage water seal vacuum pump model 2PV52120/12/43/1, driven by 10 HP 3/60/460V 1760 RPM motor. A horizontal 125 square foot 316 stainless steel tubes, tube sheets, heads, carbon steel shell heat exchanger, and a 225 gallon 316 stainless steel condensate receiver. W-202093.

45 PSI with FV internal. 6 Ft diameter body. Bull and pinion gear 230/460 volt gear head motor with electric brake, 5 rpm rotation for a 1.08 rpm bucket rotation Mechanical seal on shaft 18" carge prort with cover, Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the pltform out of the way during dryer cycle.

45 PSI with FV internal. 6 Ft diameter body. Bull and pinion gear 230/460 volt gear head motor with electric brake 5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft, Hastelloy 276-C vacuum arm. 18" carge prort with cover Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.

REBUILT

dryer rotation speed 0,8 – 4rpm IP54 motor, 220-380V

openings dryer:

(1) 500mm loading port,

(1) 320 liter carbon steel horizontal oil circulation tank, manufactured by Klein, serial number A787, internal pressure 0 bar @ 300 degrees C, 700mm diameter x 1000mm straight side, weld dished heads, openings: top (1) 50mm, (1) 20mm, side wall: (1) 75mm, bottom: (2) 25mm, (1) 38mm.

(1) 5m² cylindrical block graphite heat exchanger, manufactured by Sigri, type DK72-214063 serial number 8972, tube pressure 6 bar @ 170 degrees C (volume 15 liter), shell pressure 6 bar @ 170 degrees C (volume 26 liter), 300mm diameter x 1700mm straight side. Openings: tube side (2) 50mm, shell side (2) 75mm.

(1) Polypropylene horizontal condensate receiver, 550mm diameter x 900mm straight side, flat heads, openings top: (1) 25mm, (2) 50mm, side wall: (2) 100mm sight glasses, bottom: (1) 25mm, mounted on carbon steel frame.

(1) 0,5m² Hastelloy B jacketed fine dust collector, manufactured by Alb. Klein (Germany), serial number 51.0065/2, internal pressure -1 bar @ 250 degrees C, (volume 140 liter), jacket pressure 2,5 bar @ 250 degrees C (volume 7 liter),

(1) 40 liter/min water seal vacuum pump, manufactured by Sulzer Burckhardt, type PMH156D2X3, serial number 101264, driven by a 4,6kW/3~/50Hz/220-380V/2890rpm, ExeIIT4 motor, with a 1,5m² 316 stainless steel steam condenser, manufactured by Sulzer Burckhardt, type APOVAC PMH156D2X3, serial number 49126, Volume 40 liter, tube pressure rated full vac @ 50 degrees C, shell pressure rated 3 bar @ 50 degrees C, (31) tubes, 25mm outside diameter x 800mm long on 60 degrees pitch, shell 250mm diameter x 800mm long, welded mounted on 316 stainless steel pot, 800mm diameter x 500mm straight side, Top head is bolted dished, openings: (1) 40mm on exchanger head, (2) 25mm on exchanger shell; (1) 25mm on top of receiver, (2) 80mm sight glass on receiver straight side, (1) 25mm center bottom outlet, mounted on legs.

(1) U-tube and carbon steel shell heat exchanger, manufactured by Klein, serial number 510065A, tube pressure 6 bar @ 300 degrees C (volume 10 liter), shell pressure 6 bar @ 200 degrees C (volume 42 liter), 250mm diameter x 1000mm straight side, mounted on (2) carbon steel welded saddles..

(1) 12m³/h @ 25m head carbon steel centrifugal pump, manufactured by Allweiler AG, serial number P38345, driven by a 3kW/3~/50Hz/380V/2880rpm, IP 54 motor.

Misc, stainless steel / carbon steel pipes.

Designed to German TUV standards chamber 1100mm diameter With 400mm diameter charge port with cover With vacuum dust filter, 0.5 square meter condenser vacuum pump rated 200 cbm/hr, Type GMA10.1HV, Serial #202755 ExeG3B5 motor With piston blower, Type GLa-10-1-HV, driven by 2.5 KW, 3/50/380 volt, 3000 rpm ExG3B3 motor. With condensate receiver 324mm diameter x 480mm straight side, flat bottom, dished top, with top mounted 0.5 square meter vertical steam condenser, 1600mm diameter x 740mm straight side. With Hastelloy C4 vacuum dust filter 325mm diameter x 340mm straight side x 295mm conical section with 158mm diameter bottom discharge. With 12 KW electric heater. Double cone shell 1000mm diameter x 325mm straight side x 380mm conical sections. Charge port 400mm diameter, discharge port 150mm diameter.

dryer/ blender Lined with glass 3009 top opening. 17" charge port with cover, 8" discharge.

auftr #215140, glass 2008 1009mm high top cone and 1111mm high bottom cone gear driven by a SEW -Usocome vari-speed drive 220/380 volt, rotary union joint, top cone with a 450mm manway, bottom cone with a 200mm with valve dryer with (1) 0.6 m3/hr @ 175 deg C Pasilac s/steel plate heat exchanger, (18) 130mm wide x 450mm high s/steel plates,

1000 liter, jacketed double Cone Vacuum Dryer Blender with Hastelloy vacuum arm;

geared motor;

Body rotation speed range: 1.65 – 10 rpm;

Complete with stuffing box seal, and rotary Joint.11

15 liter capacity in body and 193 liter capacity in jacket; 3/50/220/380 volt

MDMT -20F @ 15/-15psi. Inside wall 316stainless steel Shell 78" diameter x 16" straight side x 42" cone 84" overall length

Conaform jacketed vacuum tumbling dryer system internal pressure 3,5 atü (4,5 bar) @ 148 deg C, jacket 0,4 atü @ 148 deg C (155ltr) vari-speed drive, rotary union joint, outlet with manual discharge valve system includes (1) Quadro Comill stainless steel mill 800mm diameter x 940mm straight side 1000-30 rpm, driven by 1.5kw, 3/50/400 volt, (1) type ITH418EX oil heater, 3,3kw @ 300 deg C, 3/50/380 volt, with centrifugal feed pump

Oblicone' double cone vacuum dryer external rotary union 380/420 volt Openings: 1-250mm diameter feed with manway (with hinged clamped cover), 1-200mm discharge with valve

jacketed 'Oblicone' double cone vacuum dryer external rotary union Top cone section 400mm long x 300mm straight side x 900mm bottom cone section 380/420 volt Openings: 1-250mm diameter feed with manway (with hinged clamped cover), 1-200mm discharge with valve

internal pressure -1 bar @ 200 degrees C jacket 6 bar @ 200 degrees C 1625 ltr total capacity

double cone vacuum dryer internal pressure -1/+6 bar @ -10/+200 degrees C (448 liter), jacket -1/+6 bar @ -10/+200 degrees C (110 liter),

220/380 volt EEx-d motor with Rossi variable speed variator 150mm diameter hastelloy C vacuum arm openings top 600mm diameter with manway cover, bottom 200mm diameter

60 degree cones, insulated with 321SS shroud over insulation 18" charge port with cover
