All Equipment Mills Shot And Sand

Mill Inventory - Search Shot And Sand Mills | IPP

Used mills for sale: particle size reduction equipment for powders, slurries and solids

Searching equipment…
Active Filters
Equipment
Mill
Subtype: Shot And Sand
Clear all filters

Top Shot And Sand in stock

Highest-ranked available inventory for this selection.

Compare related Mill types

Refine Shot And Sand

Specifications

Available Shot And Sand

Showing 25 of 33 matching Shot And Sand.

Stock Number: #92512
Diameter: 36 in
Drive Power: 7.5 HP
Additional Information: attritor Size 100S 30" deep tank, with 2 1/2" dia shaft, (6) cross bars. Canter lever tilt mechanism 7 1/2 HP Class I, Div II drive.
More Details ⟶
Stock Number: #213804
Capacity (Design): 0.06 m3
Diameter: 300 mm
Additional Information: Wet Grinding Media Mill water cooled grinding chamber Batch size 200 to 1000 liter capacity closed design grinding chamber,axial flow. Mechanical Seal on shaft, with Teflon grinding discs for agitating the grinding media 50 HP motor, 3/60/230/460 volt Class1 Groupd D
More Details ⟶
Stock Number: #32339
Diameter: 7 in
Drive Power: 15 HP
Additional Information: 4-station small media sandmill system, that provides continuous wet milling for aqueous and solvent slurries of all viscosities The system consists of (4) closed head, 7" dia x 17" long sandmills mounted on common base. (2) mills have CS bodies w/304SS discs, (1) mill has 304SS body and 304SS discs, (1) mill has 304SS body w/teflon discs. Each mill chamber has a water jacket designed to carry heat away so product doesn't over heat. Specs include: gross volume (gal) 5.5, 35-75 gallons per hour. Media load based on: 1.5 mm glass=40 lbs., 1.0 mm steel=80 lbs.
More Details ⟶
Stock Number: #214767
Capacity (Design): 0.2 ft3
Drive Power: 2 HP
Drive RPM: 2,000
Powered By: Electric
Additional Information: Intermittent type Attritor Szegvari Attritor System Size 1S Bench top size, with a Reeves Vari -drive rated for 276 through 2000 rpm Mixing shaft belt driven chrome plated mixing pot for 0.8 gallons working capacity with jacket for cooling or heating This mixer is designed for media size of 1/8” through 3/8” Hardened 304 SS tool steel mixing shaft Standard mixing arm pinned to shaft which means this machine is designed for ease of shaft or arm change Multiple options for mixing shafts, types of mixing chambers, lids, etc
More Details ⟶
Stock Number: #203708
Diameter: 140 mm
Drive Power: 3.3 kW
Additional Information: Dyno Mill bead mill 1.4 ltr grinding chamber 8-40 kg production rate weight 90 kg. 2 x clamps to remove chamber
More Details ⟶
Stock Number: #104551
Capacity (Design): 0.01 m3
Diameter: 290 mm
Pressure: 4 bar
Additional Information: 15 liter horiz jkt (disintegrator) mill system Rotor deviding plate 1.4435. (8) agitation discs are polyurethane clad (Bayer Vulkolan). Double jkt 304SS. Shaft seal: double lip (teflon), mfd by Garlock. Milling cylinder 15 liter volume Suspension inlet 25mm, suspension outlet 25mm. Cooling medium inlet 12mm, cooling medium outlet 12mm. Max operating pressure in milling chamber 4 bar. Max operating pressure in double jkt 2 bar Mill motor: 15 KW Loher Type eA180MA-4, 3/50/500 volt, 1455 rpm Ex-e-G3 motor
More Details ⟶
Stock Number: #212767
Capacity (Design): 0.18 m3
Drive Power: 75 kW
Additional Information: Dyno-bead mill 3x500 volt
More Details ⟶
Stock Number: #214763
Drive Power: 73 HP
Pressure: 58 psi
Temperature: 90 °C
Additional Information: coBall mill This production size stirrer-bead mill is designed for the finest grinding of suspensions and high viscous products down to Nano- Range. This mill has the following specifications: Throughput; 0.7-2.2 gpm, Pressure resistance; 58 psi, Grinding chamber volume; 2 Gallons, Rotor driving capacity; 49-73 hp, weight 3850 lbs.
Controls are 110 volt, Machine 460 volt. Air humidity from 0-80%, Ambient air; As dust free as possible. Mechanical seal on grinding chamber
More Details ⟶
Stock Number: #219894
Capacity (Design): 0.06 m3
Diameter: 300 mm
Powered By: Electric
Additional Information: barrel internal chrome plated horizontal jacketed pearl mill mechanical seal (10) 260mm diameter blades on shaft hinged front cover, built on controls, chamber on rollers for cleaning/maintenance,
More Details ⟶
Stock Number: #99807
Diameter: 6.5 in
Drive Power: 20 HP
Additional Information: 4-station Premier type small-media sandmill system. Consists of (4) 6 1/2" ID x 12" 304SS closed head horiz chambers mtd on common unit. Each chamber has rotary gear pump mtd underneath. W/controls and gauges.
More Details ⟶
Stock Number: #216258
Capacity (Design): 0.02 m3
Additional Information: lower vari drive assembly Fits 100 system only.
More Details ⟶
Stock Number: #213816
Capacity (Design): 0.02 m3
Diameter: 220 mm
Additional Information: Wet Grinding media mill water cooled grinding chamber Batch size 50 to 250 liter capacity closed design grinding chamber,axial flow. Mechanical Seal on shaft, with Teflon grinding discs for agitating the grinding media
More Details ⟶
Stock Number: #214765
Drive Power: 4 HP
Pressure: 29 psi
Temperature: 90 °C
Additional Information: This lab size stirrer-bead mill is designed for the finest grinding of suspensions and high viscous products down to Nano- Range This mill has the following specifications: Throughput; 0.044-0.132 gpm, Pressure resistance;29 psi, Grinding chamber volume; 0.13 Gallons,
Rotor driving capacity; 4 hp, weight 353 lbs.
Controls are 110volt, Machine 460 volt.
Operating conditions: Temperature; from 0-90 degrees C. Air humidity from 0-80%, Ambient air; As dust free as possible. Mechanical seal on grinding chamber
More Details ⟶
Stock Number: #105429
Diameter: 6 in
Drive Power: 5 HP
Additional Information: bead mill Type 574-04-21, Order #201869. Full load 14.7 amp. Currently set up as a disk agitator, but can also be used with a peg agitator.
Nylon coated concentric disc arrangement; nylon coated SS shaft. Has water cooled chamber w/1 HP Viking CS rotary pump Polished grinding chamber 6" dia x 18" long. On board explosion proof controls
More Details ⟶
Stock Number: #104552
Diameter: 408 mm
Additional Information: jacketed horizontal disc mill, designed for wet ginding With a jacketed grinding chamber V-belt through a Voith fluid coupling.
More Details ⟶
Stock Number: #207109
Capacity (Design): 0.25 ft3
Pressure: 1 bar
Temperature: 98 °C
Additional Information: bead mill mechanical seal on shaft cooling water pressure max 3 bar, milling vessel pressure max 3 bar, max temp. 70°C, vessel rubber lined
More Details ⟶
Stock Number: #216255
Diameter: 80 mm
Additional Information: Rebuilt 80MM mechanical seal Part #630598U, Ref. assembly #639183, Ref. dwg. # C-2115381X. Rebuilt by Netzsch June 2008.
More Details ⟶
Stock Number: #216259
Diameter: 70 mm
Additional Information: Rebuilt 70MM mechanical seal Part #630597U, Ref. assembly #638208, Ref. dwg #C-2121191X.
Rebuilt by Netzsch May 2008.
More Details ⟶
Stock Number: #216252
Diameter: 70 mm
Additional Information: Rebuilt 70MM mechanical seal Part #630597U Ref. assembly #638208, Ref. dwg #C-2121191X. Rebuilt by Netzsch May 2008.
More Details ⟶
Stock Number: #216253
Diameter: 70 mm
Additional Information: Rebuilt 70MM mechanical seal Part #630597U, Ref. assembly #638208, Ref. dwg. # C-2121191X. Rebuilt by Netzsch May 2007.
More Details ⟶
Stock Number: #216254
Diameter: 80 mm
Additional Information: Rebuilt 80MM mechanical seal Part #630598U, Ref. assembly #630971, Ref. dwg. #C-2115381X. Rebuilt by Netzsch July 2008.
More Details ⟶
Stock Number: #203418
Capacity (Design): 0.22 m3
Diameter: 17.5 in
Additional Information: jacketed, Mecha Gaper grain mill motor with UL label.
Closed design suitable for solvent based coatings. Chamber is has a SS cooling jacket Disks are UHMW (non metalic high wear material).
Bottom inlet, top discharge, with top sample port, all with sanitary style fittings.
More Details ⟶
Stock Number: #214766
Capacity (Design): 0.13 ft3
Drive Power: 0.25 HP
Powered By: Electric
Additional Information: Intermittent type Attritor. Szegvari Size 1, Bench top size. Electronic variable speed control.
More Details ⟶
Stock Number: #203417
Capacity (Design): 0.22 m3
Diameter: 17.5 in
Additional Information: 220 liter (60 gallon) jacketed, Mecha Gaper grain mill.
with UL label.
Closed design suitable for solvent based coatings. Chamber has a SS cooling jacket Disks are UHMW (non metalic high wear material).
Bottom inlet, top discharge, with top sample port, all with sanitary style fittings.
More Details ⟶
Stock Number: #203411
Capacity (Design): 0.22 m3
Diameter: 17.5 in
Additional Information: Dual Mounted jacketed, Mecha Gaper grain mills The design is two seperated complete mill mounted on a common stand. with UL label Closed design suitable for solvent based coatings Each chamber has a SS cooling jacket and a SS internal liner designed for easy replacement/maintenance Disks are UHMW (non metalic high wear material).
Bottom inlet, top discharge, with top sample port, all with sanitary style fittings.
More Details ⟶

Shop used, surplus and secondhand mills from IPP – in stock and trusted by chemical, pharmaceutical, food and mineral processors

Get consistent particle sizing with IPP’s ready-to-ship grinding and pulverizing systems

Used mills are essential in industries where reducing solid materials to fine powders or controlled particle sizes is critical. Whether you’re grinding active pharmaceutical ingredients, pulverizing pigments, or micronizing mineral fillers, mills offer the precision and flexibility needed for modern process demands. With more than 47 years of experience, IPP provides used, surplus and secondhand milling systems from 20 global plant sites and maintains a ready-to-ship inventory of 15,000+ systems.

IPP stocks a wide range of industrial mills, including hammer mills, jet mills, ball mills, colloid mills, attrition mills, and roller mills from leading brands like Hosokawa, Fitzpatrick, Netzsch, Pallmann and WAB.

Applications and industries

  • In pharmaceuticals, for micronizing APIs and excipients to improve bioavailability
  • In food and beverage, for grinding spices, sugars, grains and dairy ingredients
  • In chemicals and pigments, for dispersing solids into coatings, inks and additives
  • In mineral processing, for dry or wet milling of calcium carbonate, kaolin and metal ores

Types of materials processed

  • Dry solids such as powders, resins, pigments and minerals
  • Wet slurries requiring emulsification or particle dispersion
  • Heat-sensitive materials needing low-impact, cryogenic or inert atmosphere milling

Common materials of construction

Mills must be built to handle abrasive, corrosive or sanitary materials:

  • 304 or 316L stainless steel for food, pharma and hygienic applications
  • Hardened carbon steel or tool steel for heavy-duty mineral and metal grinding
  • Ceramic-lined or jacketed designs for corrosive or temperature-controlled processes

Key features of industrial mills

  • Fine and ultrafine particle size capability (down to sub-micron levels)
  • Configurable for batch or continuous operation
  • Explosion-proof and dust containment options for safety
  • Variable-speed controls and screen size flexibility
  • CIP-ready and cGMP-compliant models available

Explore how to select the right mill for your process from Chemical Processing.

Find your mill at IPP

Search the IPP inventory or contact IPP’s grinding and milling specialists to find the right used, surplus or secondhand mill for your operation. Whether upgrading, scaling up or replacing worn systems, IPP delivers cost-effective solutions with minimal downtime.

Mill FAQ

Have questions about Mills or our services? Learn more about our products and why customers choose IPP.

What’s the difference between a hammer mill and a jet mill?
Hammer mills use impact force to break down materials, while jet mills use compressed air or gas to achieve ultra-fine particle sizes without heat.
Can used mills meet cGMP or FDA standards?
Yes – IPP offers stainless steel and sanitary-grade mills suitable for regulated pharmaceutical and food production.
What materials can be processed in a colloid or attrition mill?
These mills are ideal for emulsions, pastes, and slurries containing soft solids or thickened mixtures.
What are the benefits of buying used or secondhand process equipment from IPP?
IPP provides faster lead times, substantial savings, and over 47 years of industry experience to guide your purchase.
