Used basket centrifuges for sale: high-speed separation for industrial solids and liquids
Highest-ranked available inventory for this selection.
Used basket centrifuges for sale: high-speed separation for industrial solids and liquids
Set a numeric threshold to narrow the matching listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 25 of 68 matching Auto Discharge-Bottom.
top load, bottom discharge, 12mm thick basket, 3.15 square meter filter area, 1100 rpm permissible speed single motion plow driven by a hydraulic powerpack, powerpack driven by approx 0.75kw EX motor, mounted on a steel baseplate,
clarifier basket centrifuge bottom discharge (2) horizontal baffles basket capacity 7.6 cu ft. 316SS basket, curb and plow Top driven by hydraulic powerpak Hinged access port 1" rotary pneumatic skimmer
top load, bottom discharge semi automatic Unit has 316SS basket, 304SS curb and Cover unit has pneumatic operated plow hydraulic basket drive hydraulic powerpack and controls
top load, bottom discharge wall thickness of the basket 12mm lid with assist mechanism basket with electric motor
316 SS curb, 316 SS lid Job 362370 Auto Bottom discharge Oil Gear hydraulic drive Top hinged access/inspection door spray wash bar & pneumatic plow Has SS discharge chute With control panel for main power.
wall thickness of the basket 14 mm holes 8 mm with 50 mm distance Top load, cake is discharged with a small peeler that scrapes the cake from the side walls and Auto bottom discharge
basket wall thickness 12mm 316/Ti s/steel (1.4571) housing Gas tight at 0.2 bar pressure. hydraulic plow, powerpack
hastelloy lined centrifuge 3 speed ,75/520/950 rpm with hydraulic power pack Top feed, bottom discharge Designed for nitrogen purge, with a pneumatic cover lock for the 1/2 hinge top cover Internally complete with a hydraulic plow, cake detector. This centrifuge is equipped with a clutch motor, hydraulic drive, and 60 HP power pack.
Motor is inverter duty.
DeLaval Mark III btm discharge perforated basket centrifuge. (2) horiz baffles. Single motion pneumatic plow. 1" rotary pneumatic skimmer. Max cake thickness 4.5" Feed pipe 1 1/2", filtrate outlet 4", solids outlet 21". Dynapower hydraulic motor. (*) (Not to be used for any drug or food application).
with rubber lined internals auto bottom discharge bottom unloading centrifuge PVC feed pipe and cake wash spray. Plow and pnuematic plow operatoin assembly 6" discharge and vent, 2" feed pipe
Unload Perforated basket centrifuge Top 316SS, Basket 316SS, curb 316SS lined Includes Pneutronic Oxygen Sensor System
Hydraulically over driven by a Dynapower Hydraulic motor PN # 896048-40, serial # 0707814. Separate power pack with a 25 HP AC motor
top load, bottom discharge semi automatic Unit has 316SS curb, lid, and internals hydraulic operated plow, hydraulic basket drive with hydraulic powerpack, and 600 gallon CS surge tank manufactued by M&M welding Power pack is located in EIN53 (RA)
top load / bottom discharge basket centrifuge without motor wall thickness of the drum 12mm, accessories on pallet, (1) carbon steel base plate.
clarifier basket centrifuge 316 stainless steel lined case, carbon steel internals. Basket 302 stainless steel. Top load and bottom discharge. No motor or controls Air/oil single motion plow. Linear skimmer". (*)
Hydraulic Drive HE-53-HYDR-131
bottom discharge perforate basket centrifuge Single motion pneumatic operated plow 9 cu ft cake capacity Variable frequency drive provided after sale
brushed finish internal, and sanitary lid is 316 SS basket is 316 SS and cone is 316 SS. pull action filter for gentle handling of material. It allows the centrifuge to function with out a scraper knife, making it ideal for sensitive products. The pneumatic pull mechanism allows for no heel to be left over after discharge. This design works excellent in the fine chemicals, pharmaceutical, and the food industries. Manufactured to GMP standards with FDA approved parts. The basket aperture is 34.5", The Feed disk drive is driven by a Reliance Duty Master serial # 01MAP61661G001CE,3 HP, 1770 RPM, 230/460v,60 Hz Inverter ready, The cover is hinged, with hydraulic power pack for lid lifting (opening). The maximum height (for lid to open) is 121.5", the maximum width is 94.5" X maximum depth of 86.6" nitrogen purged. No CIP spray balls.
Housing coated with Eldon, lid coated with Edlon, and basket coated with Edlon
cone is C-22,
Ref. No. 10889.
The model DSZ utilizes a pull action filter for gentle handling of material.
It allows the centrifuge to function with out a scraper knife, making it ideal for sensitive products
The pneumatic pull mechanism allows for no heel to be left over after discharge.
This design works excellent in the fine chemicals, pharmaceutical, and the food industries.
Manufactured to GMP standards with FDA approved parts.
Reliance Duty Master serial #02MAZ24644 G002 ZZ, 5 HP, 1750 rpm, 460v., 3 ph., 60 Hz. Frame L184 TD, TEFC Enclosure 140 Lbs..
Rated for 950 rpm, maximum charge is 500 kg.
The basket aperture is 34.5",
The maximum height (for lid to open) is 121.5", the maximum width is 94.5 X maximum depth of 86.6".
The housing is Gas tight
nitrogen purged.
Sharples Tornado-matic basket centrifuge gas type design top load bottom discharge, screen area 3 square meter, basket feed speed 600 rpm, basket was/spin speed 600/900 rpm, basket unload speed 100 rpm cake depth 180mm electric driven 304 stainless steel plow with (10) replaceable satellite plow tip segments, cake detector, 1-2" radially/coaxially adjustable feed pipe, 1-1" wash pipe with (4) spray nozzles, 1-6" filtrate, 1-30"bottom outlet
When your process demands efficient separation of solids from liquids, basket centrifuges offer reliable, high-speed solutions across a wide range of industries. With more than 47 years of process equipment expertise, IPP delivers immediate access to used basket centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used basket centrifuges from IPP helps companies minimize capital expenditures while securing proven, production-ready equipment.
Basket centrifuges operate by spinning a perforated basket at high speeds, using centrifugal force to separate solids from liquids. They are essential for batch and continuous separation processes in industries ranging from pharmaceuticals to wastewater treatment. Their design allows for efficient handling of a wide variety of slurries, pastes, and particulate-laden liquids.
Basket centrifuges are engineered to endure tough processing conditions while maintaining product purity:
High centrifugal forces for rapid and thorough separation
Perforated or imperforated basket options for different process needs
Designs for manual, semi-automatic, or fully automatic operation
Adaptable for batch or continuous processing
Easy disassembly for cleaning, inspection, and maintenance
Learn more about solid-liquid separation techniques from Chemical Processing.
Search the IPP inventory or contact IPP’s equipment specialists to find the right basket centrifuge for your separation needs. With ready-to-ship inventory, IPP helps companies maintain uptime, manage project costs, and meet demanding production schedules.
Have questions about Basket Centrifuges or our services? Learn more about our products and why customers choose IPP.
