Used basket centrifuges for sale: high-speed separation for industrial solids and liquids
Highest-ranked available inventory for this selection.
Used basket centrifuges for sale: high-speed separation for industrial solids and liquids
Set a numeric threshold to narrow the matching listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 25 of 57 matching Manual Discharge-Top.
top load/unload basket centrifuge 8mm thick basket lid with hydraulic assist with powerpack 50mm feed pipe, 25mm wash pipe, 85mm filtrate
highly polished 316L (1.4435) stainless steel basket centrifuge basket thickness 12mm, pressure 1.8 bar @ 150 degrees C half of the top cover hinges/opens, open/close assist driven by a power pack, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards.
top load/unload pressure 1.8 bar @ 150 deg C via a hydraulic Rexroth type 380/660 volt 1480/1475 rpm motor Thermosyphon which is hydraulic driven by the same powerpack, 2-internal spray nozzles, 1-150mm filtrate outlet half of the top cover is hinged and has a open/close assist mechanism, hydraulic panel,
top load/unload basket driven by an hydraulic motor via a hydraulic powerpack Thermosyphon which is hydraulic driven by the same powerpack 2-internal spray nozzles, 1-150mm filtrate outlet half of the top cover is hinged and has a open/close assist mechanism, hydraulic panel,
perforated basket centrifuge 316SS TI (1.4571) Half top hydraulically operated liftable cover Basket thickness 10mm Hydraulic operated knife. W/hydraulic powerpak, mfd by Hydramatic. Hydraulic driver Type A2P W/250mm sight glass
perforated basket centrifuge EX motor with air cooling fan mounted on top driven by 0.12 KW 3/50/380 volt motor.
Heine 316SS (V4AE) Basket thickness 6mm Pneumatic operated liftable half top cover. W/1-200mm sight glass, 1-100mm sight glass, 2-25mm, 1-50mm, 1-75mm; 1-100mm discharge W/hydraulic motor and W/hydraulic powerpak
vertical top load/bottom discharge centrifuge wetted parts are hastelloy (2.4610) 6mm basket wall thickness hydraulic drive for knife and cover
Mirror Polished finish designed for GMP & Sanitary use. 316 SS perforated Basket 22KW Crompton Breaves drive w/ dynamic braking Hydraulic power pack Flame proof control panel Overall dimensions 2000mm L x 1500 mm W.
1.4581 perforated basket centrifuge. Half top hydraulically operated liftable cover. Basket thickness 10mm Hydraulic operated knife. mfd by Hydramatic, hydraulic driver Type A2P. W/250mm sight glass
manual discharge top wall thickness of the basket 6mm
perforated basket centrifuge Half top cover liftable Basket thickness 8mm Temp sensor 500mm dia feed pipe No drive
perforated basket centrifuge, Top load/bottom discharge design. Hinged half moon shaped top cover, cover 837mm long x 431mm wide. stainless steel manaul 2-motion plow. Openings: feed pipe 85mm, filtrate 2-80mm, solids 2-710mm x 100mm wide curved outlets, sight glasses: 1-215mm, 1-125mm, 1-50mm.
perforated basket basket wall thickness 6mm hydraulic driven plow with powerpack lid with hydraulic assist 50mm feed pipe, 25mm wash pipe,
perforated basket Perforation 3mm diameter 725/1470 rpm flameproof motor Handbrake with (2) spray nozzles 2-125mm sight glasses 50mm filtrate
sanitary perforated basket centrifuge 140 kg wet material with handbrake openings: 2-75mm feed pipes, 1-75mm filtrate outlet, 2-75mm sightglasses
316SS TI (1.4571) clarifier basket centrifuge Jkt case fully liftable cover w/pneumatic operated cylinder Max basket speed 2300 rpm. 38mm feed, spray nozzles, 1-100mm sight glass, 1-175mm sight glass; 1-100mm liquid discharge
perforated basket centrifuge Rubber lined cover and curb 1.4571 basket Hydraulic powerpak Type HF10, 130 ATU, rated 0.0743 l/rpm
Monel basket, monel lined curb Approximately 3.5 cubic foot cake capacity 3/0.75 HP, 1750/875 rpm Handbrake Openings: cover 1-2", 2-1"
XP motor Openings: cover 2-6" (150mm) sight glasses 3/4" (20mm), with 4-nozzles; filtrate 2-4 3/4" (120mm); curb 1-4" (100mm). Handbrake. Hinged cover 34" (862mm) diameter with counterbalance weight. (*)
perforated basket centrifuge Fully liftable cover w/hydraulic system Basket 12mm thick. Max load 400 kg
PTFE lined 1.4571 basket. Fully liftable cover
TUV 12mm thick basket pressure 0.3 bar @ 50 degrees C 22kw 3/50/380/660 volt half of the top cover hinges/opens, with open/close assist, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, Thermosyphon/plow driven by a hydraulic power pack, feed pipe, wash pipe with spray nozzles
pressure -1/2 bar @ 135 degrees C, 12mm thick basket cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, Thermosyphon driven by the same powerpack, feed pipe with spray nozzles.
Alloy 926 (1.4529) stainless steel Ex motor with an electric converter 27kw, 3/50/400 volt 100-1000 rpm, Thermosyphon/plow driven by an 20 liter hydraulic powerpack, driven by 1.5kw, 3/50/380 volt, 1415 rpm Ex motor, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, feed pipe with nozzles.
When your process demands efficient separation of solids from liquids, basket centrifuges offer reliable, high-speed solutions across a wide range of industries. With more than 47 years of process equipment expertise, IPP delivers immediate access to used basket centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used basket centrifuges from IPP helps companies minimize capital expenditures while securing proven, production-ready equipment.
Basket centrifuges operate by spinning a perforated basket at high speeds, using centrifugal force to separate solids from liquids. They are essential for batch and continuous separation processes in industries ranging from pharmaceuticals to wastewater treatment. Their design allows for efficient handling of a wide variety of slurries, pastes, and particulate-laden liquids.
Basket centrifuges are engineered to endure tough processing conditions while maintaining product purity:
High centrifugal forces for rapid and thorough separation
Perforated or imperforated basket options for different process needs
Designs for manual, semi-automatic, or fully automatic operation
Adaptable for batch or continuous processing
Easy disassembly for cleaning, inspection, and maintenance
Learn more about solid-liquid separation techniques from Chemical Processing.
Search the IPP inventory or contact IPP’s equipment specialists to find the right basket centrifuge for your separation needs. With ready-to-ship inventory, IPP helps companies maintain uptime, manage project costs, and meet demanding production schedules.
